Name: Delock DisplayPort Adapter DisplayPort plug, DisplayPort socket Black 66297 8K UHD, gold plated connectors DisplayPort c
Brand: Delock
SKU: 3380723

A black adapter with a DisplayPort plug and an HDMI socket, enabling connection between DisplayPort and HDMI devices.

Black DisplayPort angle adapter with male and female connectors for easier connection in confined spaces.

1/2

Product type

DisplayPort cable

Connection type

DisplayPort

Version

Adapter

Connection type

DisplayPort to DisplayPort

Connections

DisplayPort plug

DisplayPort socket

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Connection1 Form factor: Right
Connection2 Form factor: Straight
Data transfer rate 32.4 Gbps

Product type: DisplayPort cable

Connection type: DisplayPort

Version: Adapter

Connection type: DisplayPort to DisplayPort

Connections: DisplayPort plug
DisplayPort socket

DisplayPort version: DisplayPort 1.4

Connector version: angled

Resolutions (max.): UHD 8K @ 60 Hz

Video resolution: 7680 x 4320 Pixel

Max. frequency: 60 Hz

Transfer rate (max.): 32.4 GBit/s

Factory colour: Black

Cable features: 8K UHD
gold plated connectors

Signal flow: Unidirectional (A→B)

Cable use: TV/monitor

Depth: 30.3 mm

Height: 12 mm

Width: 31.6 mm

Display resolution: 7680 x 4320 Pixel

Frame rate: 60 Hz

UKCA: yes

Quantity per pack: 1 Stück(e)

HDCP: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3380723 Delock DisplayPort Adapter DisplayPort plug, DisplayPort socket Black 66297 8K UHD, gold plated connectors DisplayPort c

Description

With this adapter from Delock, the DisplayPort socket of a device can be bent by 90°. This enables the connection of a cable in hard-to-reach places.

This text is machine translated.

Features

Connections:
1 x DisplayPort connector >
1 x DisplayPort socket
DisplayPort 1.4 specification
Downwards compatible to DisplayPort 1.3, 1.2 and 1.1
Pin 20 connected (supports 3.3 V)
Gold-plated contacts
Data transfer rate of up to 32.4 GB/s.
Resolution up to:
Monitor with DSC support 7680 x 4320 @ 60 Hz
Monitor without DSC support: 7680 x 4320 @ 30 Hz
(Depending on the system and the connected hardware)
Supports Display Stream Compression 1.2 (DSC)
Supports HDR
Supports HDCP 1.4 and 2.2
Dim. (LxWxH): Approx. 30.3 x 31.6 x 12.0 mm
Colour, black

Description

With this adapter from Delock, the DisplayPort socket of a device can be bent by 90°. This enables the connection of a cable in hard-to-reach places.

This text is machine translated.
