Buy Delock Series Adapter [1x Mini SAS plug - 1x M.2 Key E socket] Red

Delock Series Adapter [1x Mini SAS plug - 1x M.2 Key E socket] Red-0

Delock Series Adapter [1x Mini SAS plug - 1x M.2 Key E socket] Red-1

1/2

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Adapter Mini PCIe to M.2 Key E slot

Highlights & Details

built-in
Host Interface: Mini PCI Express
Output interface M.2
Red

Technical specifications

Host Interface: Mini PCI Express

Product type: Series Adapter

Connection type: Mini PCI Express
M.2 NGFF

No. of A connectors: 1 x

Type A: Mini SAS plug

No. of B connections: 1 x

Type B: M.2 Key E socket

Version: Adapter

Factory colour: Red

Cable use: Series

Range of use: Serial/parallel port adapters

Cable design: Round

Depth: 54 mm

Width: 30 mm

UKCA: yes

Internal: yes

Manual: yes

Documents & Downloads

Datasheet

Datasheet 3381267 Delock Series Adapter [1x Mini SAS plug - 1x M.2 Key E socket] Red

User & Safety Instructions

User & Safety Instructions 3381267 Delock Series Adapter [1x Mini SAS plug - 1x M.2 Key E socket] Red

Description

An M.2 module in 2242, 2230, 3042 or 3030 format can be connected to this adapter from Delock. The adapter is integrated in the system via the mini PCIe interface. Due to the predetermined breaking points, the adapter can be shortened from full size to half size.

This text is machine translated.

Features

Connections:
1 x mini PCIe plugs
1 x 67 Pin M.2 Key E Slot
Interface USB 2.0 / PCIe
Form factor: Mini PCIe full size/half size
Supports M.2 modules in the format 2242, 2230, 3042 and 3030 with Key E
Or key A+E on USB/PCIe basis
Maximum height of the components on the module: 1.5 mm,
Use of modules equipped on two sides possible
Dim. (LxB): Approx. 54 x 30 mm

System requirements

Linux Kernel 3.2 or later
Windows 7/7-64/8.1/8.1-64/10/10-64/11
Motherboard with a free mini PCIe slot with USB / PCIe interface
