Delock USB 2.0 Adapter [1x USB-C® plug - 1x Mini DisplayPort] 63939 0.03 m
EAN:
Part number:
Item no:
Highlights & Details
Delock USB Type-C adaptor to mini DisplayPort (DP Alt Mode) 4K 60 Hz keychain
- 0.03 m
- USB Type-C Straight Male
- Mini DisplayPort Straight Female
- 3840 x 2160 pixels
Technical specifications
- Connection1 Form factor: Straight
- Connection2 Form factor: Straight
- Connection 1 USB Type-C
- Connection 2: Mini DisplayPort
- Product type
USB 2.0 Adapter
- Connection type
USB-C®
Mini DisplayPort
- No. of A connectors
1 x
- Type A
USB-C® plug
- No. of B connections
1 x
- Type B
Mini DisplayPort
- Cable length
0.03 m
- Factory colour
Black
- Connector version
straight
- Cable use
USB 2.0
- Version
Adapter
- Range of use
USB adapters
- Cable design
Round
- Display resolution
3840 x 2160 Pixel
- Connections
RJ45 connector
- Supported OS
Android
- UKCA
yes
- Plug and Play
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3378977 Delock USB 2.0 Adapter [1x USB-C® plug - 1x Mini DisplayPort] 63939 0.03 m
Description
This Delock adapter is designed to connect a DisplayPort monitor to a computer with a USB-C™ interface and DisplayPort Alternate Mode support. Thus, the adapter can be connected to different laptops like the MacBook, Chromebook and the like. In addition, the adapter can be operated via a Thunderbolt™ 3 interface. Due to the small size of the adapter it is ideal as a companion while traveling.
This text is machine translated.
This text is machine translated.
Features
- Connections:
- 1 x USB Type-C™ connector >
- 1 x mini DisplayPort 20-pin socket
- Chipset: VIA VL100
- DisplayPort 1.2 specification
- Resolution up to 3840 x 2160 @ 60 Hz
- (Depending on the system and the connected hardware)
- Transmission of audio and video signals
- USB bus Power
- Plug & Play
- Cable length without connections: Approx. 3 cm
- Colour, black
System requirements
- Android 6.0 or higher
Chrome OS
IPad Pro (2018)
Linux Kernel 4.3.3 or later
Mac OS X 10.13.3 or higher
Windows 7/7-64/8.1/8.1-64/10/10-64
Windows 10 Mobile
PC or laptop with a free USB Type-C™ port
And DisplayPort Alternate Mode or
PC or laptop with a free Thunderbolt™ 3 port
