Deye Inverter SUN-6K-SG05LP3-EU-SM2 6000 W 550 V - 400 V Remote operation

The Deye SUN-6K-SG05LP3-EU-SM2 is a three-phase hybrid inverter for solar energy use in private and commercial applications. It combines inverter, battery charger and energy management system, Ideal for new and retrofit devices in order to increase your own consumption rate and safeguard the power supply.

Efficient energy conversion for modern requirements

The Deye SUN-6K-SG05LP3-EU-SM2 achieves a maximum efficiency of 97.6 percent and an MPPT-efficiency of over 99 percent. Thanks to its wide MPPT voltage range from 200 to 650 volts, the inverter is stable and efficient even in variable lighting conditions. In this way, energy losses are minimized and the energy yield of the solar system maximized.
Flexibility and scalability

The Deye SUN-6K-SG05LP3-EU-SM2 can be flexibly adapted to different requirements by the possibility of parallel connection of up to ten units. The AC coupling allows easy retrofitting of existing solar systems without the need for major modifications. The inverter supports both lead-acid and lithium-ion batteries, enabling individual storage solutions. Because of the time-based battery management the charging and discharging processes can be specifically adjusted to low power tariffs, in order to further reduce operating costs.
Reliability and protection

With a degree of protection of IP65, the inverter is protected against dust and water and is also suitable for use in demanding environments. The wide operating temperature range from minus 40 to plus 60 degrees Celsius ensures stable operation under different climatic conditions. Extensive protection functions, including reverse polarity, over current and overvoltage protection, thermal protection mechanisms and the monitoring of the DC insulation impedance, ensure maximum safety and longevity of the system.
Who is the Deye SUN-6K-SG05LP3-EU-SM2 for?

This inverter is Ideal for

-Home households that want to increase their own consumption and reduce energy costs
-Businesses that rely on a flexible and safe power supply
Users who want to add a modern storage solution to existing solar systems
Installations in regions with unstable grid supplies where diesel generators are used as an additional energy source

FAQ for 6kW Deye SUN three-phase hybrid inverter

What types of batteries does the inverter support?

The inverter is compatible with lead-acid and lithium-ion batteries in the voltage range from 40 to 60 volts.
Can the inverter be operated with a diesel generator?

Yes, the Deye SUN-6K-SG05LP3-EU-SM2 supports the integration of diesel generators and enables an uninterrupted power supply.
Is the inverter suitable for retrofitting existing plants?

Yes, the inverter can be easily integrated into existing solar systems thanks to AC coupling.
What is the maximum charge and discharge current?

The maximum charging and discharging current is 135 ampere respectively, WAS enables a fast transmission of energy.
Does the Deye SUN-6K-SG05LP3-EU-SM2 have a remote shut-down function?

Yes, the inverter supports immediate remote shutdown in the event of an accident.
