di-soric Proximity sensor Inductive 215253 215253 shielded NPN (L x W) 16 mm x 16 mm
EAN:
Part number:
Item no:
Product type
Proximity sensor
Contact type
1 maker
Switching distance (max.)
2 mm
Outputs
NPN
Model
Inductive
Datasheet (PDF)
Technical specifications
- Product type
Proximity sensor
- Type
215253
- Contact type
1 maker
- Switching distance (max.)
2 mm
- Outputs
NPN
- Enclosure material
Aluminium
- Model
Inductive
- Installation type
shielded
- Connector
Cable
- Cable length
2 m
- Min. temperature
-25 °C
- Max. temperature
70 °C
- Length
16 mm
- Width
16 mm
- Depth
8 mm
- Dim
(L x W) 16 mm x 16 mm
- Content
1 pc(s)
- Supply voltage
10-30 V
DC
Metal
FALSE
2 mm
Cable
NPN
10-30 V
10-30 V
Cuboid
Concise
10-30 V
Other
8 mm
4.7 mm
16 mm
Documents & Downloads
Datasheet
Datasheet 3817810 di-soric Proximity sensor Inductive 215253 215253 shielded NPN (L x W) 16 mm x 16 mm
User & Safety Instructions
User & Safety Instructions 3817810 di-soric Proximity sensor Inductive 215253 215253 shielded NPN (L x W) 16 mm x 16 mm
User & Safety Instructions 3817810 di-soric Proximity sensor Inductive 215253 215253 shielded NPN (L x W) 16 mm x 16 mm
Description
Inductive proximity sensor Operation principle: Inductive installation: Flush switching distance: 2 mm Operating voltage: 10 . 30 V DC switching output: Npn, 200 mA, NO Evaluation: Digital Design: Quader Special features: Two times switching distance Housing material: Aluminium Size: 8 x 16 mm Housing length: 16 mm Ambient temperature Operation: -25 . +70 °C Protection class IP 67 Connection: Cable, PVC, 2 m
