di-soric Pushbutton Ultrasound 210965 210965
EAN:
Part number:
Item no:
Product type
Pushbutton
Switching distance (max.)
400 mm
Model
Ultrasound
Type
210965
Enclosure material
Aluminium
Datasheet (PDF)
Technical specifications
- Material of the cable jacket: Other
- Product type
Pushbutton
- Type
210965
- Switching distance (max.)
400 mm
- Enclosure material
Aluminium
- Model
Ultrasound
- Material properties
anodised
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP67
- Content
1 pc(s)
- Idle current
40 mA
- Supply voltage
18-30 V
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3817513 di-soric Pushbutton Ultrasound 210965 210965
User & Safety Instructions
User & Safety Instructions 3817513 di-soric Pushbutton Ultrasound 210965 210965
Description
Ultrasonic sensor Functional principle: Ultrasonic sensor, ultrasonic barrier, ultrasonic reflex barrier Nominal switching distance (Sn): 400 mm Mounting distance (Sensor to sensor): 250 mm Operating voltage: 18 . 30 VDC switching output: Push-pull, 150 mA, NO/NC Interface: IO-Link (V1.1, COM2 38.4 kBd, Smart sensor profile) Voltage drop (max.): 2 V Housing material: Aluminium, black (anodized) Ambient temperature Operation: -25 . +70 °C Protection type IP 67 Connection: Plug, M8, 4-pin
