di-soric Retroreflective photo sensor 212974 212974 Background suppression 1 pc(s)
EAN:
Part number:
Item no:
Product type
Retroreflective photo sensor
Functions
Background suppression
Type
212974
Outputs
NPN
Cable length
2 m
Datasheet (PDF)
Technical specifications
- Protection class (IP): Other
- Material of the cable sheath: Polyvinyl chloride (PVC)
- Product type
Retroreflective photo sensor
- Type
212974
- Functions
Background suppression
- Outputs
NPN
- Cable length
2 m
- Enclosure material
Polyvinyl chloride
- Transmitter type
LED red
- Wavelength
633 nm
50 mm
- Features
Incl. background suppression
- Min. temperature
-25 °C
- Max. temperature
+60 °C
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3816536 di-soric Retroreflective photo sensor 212974 212974 Background suppression 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3816536 di-soric Retroreflective photo sensor 212974 212974 Background suppression 1 pc(s)
User & Safety Instructions 3816536 di-soric Retroreflective photo sensor 212974 212974 Background suppression 1 pc(s)
Description
Reflection light sensors with background suppression Functional principle: Light sensors with background suppression Transmission light source: LED Light color: Red / 633 nm Range: 1 . 50 mm operating voltage 10 . 30 V DC switching output: Npn, 100 mA, NO Ambient temperature Operation: -25 . +60 °C Protection class III, operation at protection extra low voltage Connection: Cable, 2 m, 3-pin
This text is machine translated.
This text is machine translated.
Hints
For more information on this 212974, please refer to its datasheet under 'downloadable documents'
