di-soric Sensor Inductive 203040 203040 PNP (Ø) 4 mm
EAN:
Part number:
Item no:
Product type
Sensor
Outputs
PNP
Model
Inductive
(Ø)
4 mm
Type
203040
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
203040
- Outputs
PNP
- Enclosure material
Plastic
- Model
Inductive
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- (Ø)
4 mm
- Dim
(Ø) 4 mm
- Content
1 pc(s)
- Supply voltage
10-35 V
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3816788 di-soric Sensor Inductive 203040 203040 PNP (Ø) 4 mm
User & Safety Instructions
User & Safety Instructions 3816788 di-soric Sensor Inductive 203040 203040 PNP (Ø) 4 mm
Description
Inductive wire break sensor Evaluation: Static internal diameter: 4 mm mounting distance to metal (min.): 5 mm operating voltage: 10 . 35 VDC (Supply Class 2) Switching output: Pnp, 200 mA, NO/NC Idle current (max.): 11 mA Part speed (max.): 35 m/s Pulse extension: 10 . 150 ms Housing material: Plastic Protection type: IP 67 Ambient temperature Operation: -25 . +70 °C Connection: Plug, M12, 4-pin, A-coded
