Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 180.66 / piece)
€
Only 3 Piece(s) available
Highlights & Details
16HE wall housing 816x600x600 mm, color black (RAL 9005)
- The IT rack in 19-inch format has 16 U (height units) for mounting network and server installations as well as components for audio applications - the maximum installation depth is 45.9 cm
- There are pre-punched openings in the floor, roof and rear wall for the cable feed, which can be opened as required - the safety glass door has an opening angle of 210°
- With the removable side walls, the network splitter has a very good accessibility for the maintenance and installation of integrated IT components, such as patch field, switch or power strip
Technical specifications
- Width 600 mm
- Color: Black, RAL 9005
- Front door: Glass door, single-wing
- HEY: 16
- Cabinet type: Wall housing
- Depth: 600 mm
- 60 kg load capacity
- IP protection class IP20
- Dim
(W x H x D) 600 x 816 x 600 mm
- Factory colour
Black
Black (matt)
Black (RAL 9005)
- Depth
600 mm
- Height
816 mm
- Width
600 mm
- Rack unit
16 U
- Material
Steel plate
- Wireless charging
No
- Type
Server rack cabinet
- Weight
28400 g
- Product type
19" wall cabinet
Variants(All information is without VAT, plus shipping costs)
Material
Rack unit
Height
Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
This article
Steel plate
16 U
816 mm
Minimum order quantity: 1
Multiple: 1
€ 180.66*
Digitus DN-19 12U-6/6-EC 19" wall cabinet (W x H x D) 600 x 638.4 x 600 mm 12 U Grey-white (RAL 7035)
Steel
12 U
638.4 mm
Minimum order quantity: 1
Multiple: 1
€ 163.86*
Digitus DN-19 16U-6/6-EC 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Grey-white (RAL 7035)
Steel
16 U
816 mm
Minimum order quantity: 1
Multiple: 1
€ 184.87*
Digitus DN-19 09U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 505 x 600 mm 9 U Black, Black (matt), Black (RAL 9005)
Steel plate
9 U
505 mm
Minimum order quantity: 1
Multiple: 1
€ 138.65*
Digitus DN-19 07U-6/6-EC 19" wall cabinet (W x H x D) 600 x 416.2 x 600 mm 7 U Grey-white (RAL 7035)
Steel
7 U
416.2 mm
Minimum order quantity: 1
Multiple: 1
Digitus DN-19 09U-6/6-EC 19" wall cabinet (W x H x D) 600 x 505.1 x 600 mm 9 U Grey-white (RAL 7035)
Steel
9 U
505.1 mm
Minimum order quantity: 1
Multiple: 1
Digitus DN-19 07U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 416 x 600 mm 7 U Black, Black (matt), Black (RAL 9005)
Steel plate
7 U
416 mm
Minimum order quantity: 1
Multiple: 1
Digitus DN-19 12U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 638 x 600 mm 12 U Black, Black (matt), Black (RAL 9005)
Steel plate
12 U
638 mm
Minimum order quantity: 1
Multiple: 1
Documents & Downloads
Datasheet
Datasheet 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
Datasheet 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
Datasheet 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
Datasheet 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
Datasheet 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
User & Safety Instructions
User & Safety Instructions 2380175 Digitus DN-19 16U-6/6-EC-SW 19" wall cabinet (W x H x D) 600 x 816 x 600 mm 16 U Black, Black (matt), Black (RAL 9005)
Description
The wall housings of the Dynamic Basic series are made of a robust steel sheet construction. The stability is increased by the welding points. The side panels are removable and the wall mounting is simple and can therefore be done quickly. Due to their flexibility, the wall housing is ideal for all common IT and telecommunication applications.
This text is machine translated.
This text is machine translated.
Features
- If the passive ventilation of the wall housing is not sufficient for devices such as routers, NAS, UPS, telecommunications system, a separately available fan module can be installed in the roof of the data cabinet
- The door stop of the lockable front door can be changed from right to left as desired - ideal for the digital infrastructure in your company, home network or home office
- Lockable safety glass door with steel frames
- 210° door opening angle
- 1-point locking on the front door
- 483 mm (19") profile rails are adjustable in depth and marked with the height unit
- 483 mm (19") profile rails mounted on the front and rear inside the cabinet, galvanized
- 0.8 - 1.2 mm robust sheet steel with high load capacity, powder-coated
- Roof is prepared to accommodate a fan element (punched-out slots)
- Ventilation slots for active and passive ventilation
- 4 earthing points (bottom, side panel and front door) with protective cap
