Digitus DN-80114-1 DN-80114-1 Ethernet switch 8 ports
EAN:
Part number:
Item no:
Highlights & Details
Digitus 10" gigabit Ethernet switch, 8-port, unmanaged
- 8 × 10/100/1000Base-T RJ45 ports
- Simple Plug & Play installation.
- 10" rack mounting
- Switching capacity 16 Gbps
- MAC address table 8K
- Supports Store-and-Forward, as well as Auto-Negotiation and Auto MDI/MDI-X on all ports
- IEEE 802.3x flow control
- Fanless design
Technical specifications
- Ports 8 × 10/100/1000Base-TX
- IEEE 802.3, 802.3u, 802.3ab, 802.3x
- Switching architecture: Store-and-forward
- Forwarding: Non-blocking
- Backplane:16 Gbps
- Duplex mode: Half/full duplex auto-detection
- Flow Control: Back pressure (half duplex), 802.3x (full duplex)
- MAC addresses: 8K
- Design:10" (25 cm) rackmount, metallic casing
- Passive cooling (air-free)
- Input voltage 100–240 V AC, 50/60 Hz
- Internal power supply, power consumption: Max. 5 W.
- Operating temperature: 0 °C to 45 °C
- Humidity: 10% - 90% (non-condensing)
- Product type
Ethernet switch
- Working principle
Unmanaged switch
- Ethernet ports
8
- Port type
RJ45 ports
- Auto-uplink at each port
Yes
- Jumbo frames
Yes
- Power supply (LOV)
via PSU
- Weight
1.44 kg
- Type
DN-80114-1
- Rack size
254 mm (10")
- Interfaces
RJ45
IP20
- Factory colour
Black
- Operating voltage
240 V AC
- Max. ambient temperature
45 °C
- Min. ambient temperature
0 °C
- Port
8 ports
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3763175 Digitus DN-80114-1 DN-80114-1 Ethernet switch 8 ports
Description
Ports 8 × 10/100/1000Base-TX
IEEE 802.3, 802.3u, 802.3ab, 802.3x
Switching architecture: Store-and-forward
Forwarding: Non-blocking
Backplane:16 Gbps
Duplex mode: Half/full duplex auto-detection
Flow Control: Back pressure (half duplex), 802.3x (full duplex)
MAC addresses: 8K
Design:10" (25 cm) rackmount, metallic casing
Passive cooling (air-free)
Input voltage 100–240 V AC, 50/60 Hz
Internal power supply, power consumption: Max. 5 W.
Operating temperature: 0 °C to 45 °C
Humidity: 10% - 90% (non-condensing)
This text is machine translated.
IEEE 802.3, 802.3u, 802.3ab, 802.3x
Switching architecture: Store-and-forward
Forwarding: Non-blocking
Backplane:16 Gbps
Duplex mode: Half/full duplex auto-detection
Flow Control: Back pressure (half duplex), 802.3x (full duplex)
MAC addresses: 8K
Design:10" (25 cm) rackmount, metallic casing
Passive cooling (air-free)
Input voltage 100–240 V AC, 50/60 Hz
Internal power supply, power consumption: Max. 5 W.
Operating temperature: 0 °C to 45 °C
Humidity: 10% - 90% (non-condensing)
This text is machine translated.
Scope of delivery
- DN-80114-1 10" Gigabit switch
- Power cable;
- User manual
