Digitus DS-72212 KVM changeover switch VGA PS/2
EAN:
Part number:
Item no:
Digitus DS-72212 KVM changeover switch
Highlights & Details
- Ports: 1-port VGA, PS/2, 2x USB (for mouse/keyboard)
- Cascading: Not possible
- The modular KVM switches are interchangeable
- Full control under all operating systems, in BIOS settings, during booting or with blue screens
- Keyboard and mouse emulation for error-free booting of the computer without additional software
- Long connection cable, 1.8 m
Technical specifications
- Product type
KVM changeover switch
- No. of switchable PCs
1
- Video via
VGA
- Controller
PS/2
- No. of USB 2.0 ports
2 x
- Stackable
No
- Rack mount option
No
- Switch function
Automatic
- Distributor/switch features
meets industrial requirements
- Power supply (LOV)
not required
- Factory colour
Black
- Weight
0.2 kg
- Length
77 mm
- Width
50 mm
- Height
24.5 mm
- Dim
(L x W x H) 77 x 50 x 24.5 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1881746 Digitus DS-72212 KVM changeover switch VGA PS/2
Description
The DIGITUS KVM Switch module offers a variety of individual configuration options, so that an adjustment can be tailored to the application area of the console. As a result, the console is cost-saving and can be upgraded or converted at any time with additional modules. Thanks to the flexible configuration, a high level of future-proofing of the console is thus guaranteed. The modular KVM switch offers the connection of a server via USB or PS/2 as well as VGA. The DIGITUS 17" or 19" modular console, keyboard and the corresponding wiring kit are required for operation. The high-quality KVM switch modules with IP function (optional) are ideal for use in small to medium-sized server rooms, in which administrator access must be ensured at any time from any location. They offer direct connection from a local console or with the optional IP module via an existing Internet connection with a browser. The accessories are available in a variety of different versions.
This text is machine translated.
This text is machine translated.
Features
- Modular KVM switch for connecting a server
- Space-saving housing with 1HE height
- Suitable for modular KVM consoles DS-72210 and DS-72211
- Control of a PC via the DIGITUS modular console in 17" or 19"
- Full control under all operating systems, in BIOS settings, during booting or with blue screens
- No additional software necessary
- Remote”power wake-up” on the target computer
- Resolution depends on the console inserted
- Hot-plug support
- Keyboard and mouse emulation for error-free booting of the computer
- AutoScan (5 to 90 sec, selectable)
- Compatible with USB 2.0 specification
- Number of KVM ports: 1
- Connector type: VGA port, PS/2, 2x USB (for mouse/keyboard)
- Long connection cable, 1.8 m
- Cascading: Not possible
Scope of delivery
- Modular 1-port KVM switch
- Quick start guide Power supply assembly material
