Digitus USB-C® docking station DA-70255
EAN:
Part number:
Item no:
Digitus DA-70255 USB-C® docking station
Highlights & Details
- Connection A (or inputs): USB-C®
- Connecton B (or outputs): USB-A, RJ45
- No. of supported monitors:
- Maximum resolution:
- Key features:
Technical specifications
- Connections: 1 x 10/100/1000 Mbps RJ-45 port, 3x USB 3.0 Type A (F), 1x USB type-C-plug cable
- Product type
USB-C® docking station
- Type A
USB-C®
- Type B
USB-A
RJ45
- Suitable for
Universal
- Factory colour
Silver
- Width
95 mm
- Height
27 mm
- Depth
16 mm
- Weight
32 g
- Dim
(W x H x D) 95 x 27 x 16 mm
- Version
Adapter
- Cable use
USB 3.2 1st Gen (USB 3.0)
- Distributor/switch features
+ built-in Ethernet piort
- Interfaces (output)
USB type A
USB A (USB 3.0)
Gigabit LAN (1 Gbps)
- Port
3+1 ports
- Power supply (LOV)
via USB
- Wireless charging
No
- Connection type
USB 3.2 Gen 1 (USB 3.0)
- No. of outputs
3 x
- Product type description
Lade-/Dockingstation
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1848744 Digitus USB-C® docking station DA-70255
Description
With the DIGITUS ® USB 3.0 3-Port Hub & Gigabit LAN Adapter, you 3 additional USB 3.0 high-speed devices to your ultrabook™, notebook, ultraportables, Macbook, Macbook Air, etc. Printers, hard disks, flash-memory, card reader, speakers, and many other devices can be easily via the USB-interface. In addition, the adapter your computer to a Gigabit Ethernet port and makes it therefore network-enabled, since many mobile devices nowadays only via wireless LAN can be linked in the network.
This text is machine translated.
This text is machine translated.
Features
- Backward compatible with USB 2.0 and 1.1.
- IEEE 802.3, IEEE 802.3u and IEEE 802.3ab compatible
- Supports full-duplex with flow control and half-duplex mode with counter-pressure
- Supports twisted-pair crossover recognition and auto-correction (HP Auto-MDIX)
- Supports Wake-On-LAN
- Compatible with Mac OS, Windows 10 and Google Chrome OS
Scope of delivery
- USB type-C™ 3-Port Hub + Gigabit Ethernet
- User manual
