Dino KRAFTPAKET KFZ Batterieladegerät 20A-12V mit Camping-, Nacht-und Memory-Speicher 136320 Automatic charger 12 V 20 A

The car battery charger is an 8-step car battery charger, which is used to charge and trickle charge 12V batteries. Select the desired charging program (normal, AGM, frost, maintenance or night) and the microprocessor-controlled car battery charger does everything fully automatically until the end of the charging cycle and for trickle charging of full batteries. The German-language display is easy to understand and comfortable to use.

For continuous charging, the ring eyelet cables are firmly mounted on the vehicle battery to be charged. The car battery charger is connected to the eyelet cable via a quick-connect plug. This is very convenient as the ring eyelet cables can remain permanently on the battery.

The battery charger enables the maximum rapid charging current from 10 ampere to 85% charging. Therefore, charging is much shorter than with a conventional charger with 10A nominal current, which has a falling charging current due to its design.

Camping function:
As soon as, with the engine stopped, the vehicle battery is drawn from the battery, it is recharged programmatically. Fixed installation on the on-board power supply possible.

Low-noise night charging due to reduced charging power with reduced blower function.

After interruption of the mains current, the automatic battery charger starts in the last program used after renewed power supply.

After charging step 3, the truck can be started again. Note appears on the display.

Maintenance up to 16V
The function increases the performance and extends the life of the battery.
Night to 14.4V
Low-noise charging due to reduced charging power with reduced blower function.
Normal to 14.4V
For all 12V lead-acid batteries (except AGM)
AGM/Frost up to 14.7V
Frost and AGM function for an adapted charging process at low temperatures or for AGM batteries.
Eight charging steps:
STEP 1 “PREPARATION” TO BREAK UP THE SULPHATIZATION
Detects batteries contaminated by sulphate deposits and removes this deposit with the help of pulsating current and voltage for recovery of optimum charging capability.
STEP 2 “SOFT-START”
Checks the battery for charging capability and only starts the charging process with a 50% charging current until approx. 12.5V is reached if the result is positive. This prevents damage to the battery and the charger.
STEP 3 "FAST CHARGE” FAST CHARGE UP TO 85%
After successful testing, the device charges the battery with maximum current up to 14.4V (in the program "cold/AGM" it is 14.7V selected with "MODE" key) to a charging status of approx. 85%. In an emergency, a discharged battery is sufficiently charged after charging step 3 to restart an engine even in cold weather.
STEP 4 "REMAINING CHARGE” CHARGING UP TO 95%
Device charges up to 95% charge with decreasing current strength at constant voltage.
STEP 5 CAPACITY TEST
Tests the battery for 3 minutes of battery charge. The device evaluates whether the battery can hold the voltage.
STEP 6 "MAINTENANCE" REFRESH FUNCTION 100% (PRESS "MODE” KEY BEFORE STARTING)
The "Maintenance" function provides a controlled output of the battery acid with 16V and up to 3A. This results in a full charge and increases the life and performance of the battery.
STEP 7 “MAINTENANCE” MAINTENANCE CHARGE (100%)
Battery life is maintained at constant battery voltage 13.7V with low charging current. If not that
Charging program "Maintenance" is selected, 100% of the charge is reached in this charging step. The car battery charger works as a maintenance charger from step 7.
STEP 8 "PULSE” PULSE CHARGE (95-100 %)
After 10 days and/or if the voltage drops below 95%, the charge pulse will be 100% of the
Charge restored and sulphation prevented.
