Image similar
Image similar
Diotec GBS4M Diode bridge GBS_SIL-1.5-2.3 1000 V 2 A
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 0.99103
9
8% = € 0.08
€ 0.91125
15
11% = € 0.11
€ 0.87934
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 3
Total (€ 0.99103 / piece)
€
Technical specifications
- Type SILHousing: GBS_SIL-1.5-2.3Periodic Peak Reverse Voltage - VRRM 1000 VContinuous current - IFAV 4.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 80.00 AForward voltage - VF 1.05 VIF 2.00 AReverse current - IR 5,000 µAVR 1000 VLock layer capacity - CJ: PFVR V
- Type
GBS4M
- Enclosure
GBS_SIL-1.5-2.3
- Manufacturer
Diotec
- U(RRM)
1000 V
- Forward current I(F)
2 A
- Forward voltage U(F)
15 V
- I(FSM) 50Hz
80 A
- Reverse leakage current I(r)
5 µA
- Operating temperature (max.)
150 °C
- Mounting type
Through-hole mounting
- RoHS-compliant
Yes
- Product type
Diode bridge
Documents & Downloads
Datasheet
Datasheet 2809741 Diotec GBS4M Diode bridge GBS_SIL-1.5-2.3 1000 V 2 A
Description
Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
