A five-terminal bridge rectifier in two different views, marked with 'KBP' and symbols for terminal assignment.

Image similar

A five-terminal bridge rectifier in two different views, marked with 'KBP' and symbols for terminal assignment.

Image similar

Diotec

Our service for you

Datasheet (PDF)

English

76 Piece(s)

Sales and shipping:

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 15

Total (€ 0.2066 / piece)

€

Report legal concerns

Technical specifications

Type SILKBP casingPeriodic Peak Reverse Voltage - VRRM 400 VContinuous current - IFAV 2.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 50.00 AForward voltage - VF 1.10 VIF 2.00 AReverse current - IR 5,000 µAVR 400 VLock layer capacity - CJ 25 pFVR 4 V

Type: KBP304G

Enclosure: KBP

Manufacturer: Diotec

U(RRM): 400 V

Forward current I(F): 2 A

Forward voltage U(F): 1.10 V

I(FSM) 50Hz: 50 A

Reverse leakage current I(r): 5 µA

Operating temperature (max.): 150 °C

Mounting type: Through-hole mounting

RoHS-compliant: Yes

Product type: Diode bridge

Documents & Downloads

Datasheet

English

Datasheet 2809825 Diotec KBP304G Diode bridge KBP 400 V 2 A

Description

Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
