Image similar
Image similar
Diotec KBPC610 Diode bridge KBPC6 1000 V 3 A
EAN:
Part number:
Item no:
Product type
Diode bridge
Enclosure
KBPC6
U(RRM)
1000 V
Forward current I(F)
3 A
Forward voltage U(F)
1.20 V
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 1.22382
10
8% = € 0.10
€ 1.12530
25
11% = € 0.14
€ 1.08590
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 1.22382 / piece)
€ 1.22
plus VAT.
14-day return policy included
Technical specifications
- Type wire-leadCasing: KBPC6Periodic Peak Reverse Voltage - VRRM 1000 VContinuous current - IFAV 6.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 110.00 AForward voltage - VF 1.20 VIF 3.00 AReverse current - IR 5,000 µAVR 1000 VLock layer capacity - CJ: PFVR V
- Type
KBPC610
- Product type
Diode bridge
- Enclosure
KBPC6
- Manufacturer
Diotec
- Manuf. code
DIO
- U(RRM)
1000 V
- Forward current I(F)
3 A
- Forward voltage U(F)
1.20 V
- Forward voltage reference
3.00 A
- I(FSM) 50Hz
110 A
- Reverse leakage current I(r)
5 µA
- Reverse leakage current I(r) reference
1000 V
- Operating temperature (max.)
150 °C
- Mounting type
Through-hole mounting
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2809873 Diotec KBPC610 Diode bridge KBPC6 1000 V 3 A
User & Safety Instructions
User & Safety Instructions 2809873 Diotec KBPC610 Diode bridge KBPC6 1000 V 3 A
Description
Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
