Buy Diotec Si high voltage rectifier DD300 D2.5x6.5 3000 V 1 A

Two cylindrical electronic components with metal connections, probably diodes, against a white background.

Image similar

Product type

Si high voltage rectifier

Enclosure

D2.5x6.5

Forward current I(F)

1 A

Reverse voltage U(R)

3000 V

Forward voltage U(F)

40 V

Datasheet (PDF)

Fast track dispatch on Wed, 7 Oct

4759 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 0.17 / piece)

€ 0.17

plus VAT.

14-day return policy included

Report legal concerns

Technical specifications

Type: DD300

Product type: Si high voltage rectifier

Enclosure: D2.5x6.5

Manufacturer: Diotec

Forward current I(F): 1 A

Reverse voltage U(R): 3000 V

Forward voltage U(F): 40 V

Reverse leakage current I(r): 5 µA

Operating temperature (max.): 150 °C

Mounting type: Through-hole mounting

I(FSM) 50Hz: 3 A

Reverse recovery time T(rr): 150 ns

RoHS-compliant: Yes

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2807624 Diotec Si high voltage rectifier DD300 D2.5x6.5 3000 V 1 A

User & Safety Instructions

User & Safety Instructions 2807624 Diotec Si high voltage rectifier DD300 D2.5x6.5 3000 V 1 A
