Doepke 09916017 DLS6I B4A 1polig 10KA Circuit breaker 1-pin 4 A 230 V
EAN:
Part number:
Item no:
Product type
Circuit breaker
Number of pins
1
Release characteristics
B
Nominal current - rounded value
4 A
Nominal voltage (details)
230 V
Datasheet (PDF)
Highlights & Details
DOEPKE LS-Switch, single-pole, B-characteristic, 4 A, 10 kA, for the industry
- Quick mounting on DIN rail
- All mounting positions permitted
- Switch position indicator on the knob
Technical specifications
- Nominal voltage (details)
230 V
- Product type
Circuit breaker
- Number of pins
1
- Release characteristics
B
- Nominal current - rounded value
4 A
- Nominal current
4 A
- Dim
(W x H x D) 17.7 x 83 x 75.2 mm
- Content
1 pc(s)
- Switch-off capacity
10 kA
- Operating voltage
230 V
- Nominal voltage
230 V
- Width
17.7 mm
- Height
83 mm
- Depth
75.2 mm
- Weight
0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2136365 Doepke 09916017 DLS6I B4A 1polig 10KA Circuit breaker 1-pin 4 A 230 V
User & Safety Instructions
User & Safety Instructions 2136365 Doepke 09916017 DLS6I B4A 1polig 10KA Circuit breaker 1-pin 4 A 230 V
Description
Circuit breaker (MCB) protect cables and installation devices against overload and short-circuit and thus against damage. The series DLS6 offers a large selection of different types for use in living and purpose building and in the industrial sector. Their low profile offers a lot of space for wiring. The circuit breaker DLS6 can be easily installed by its large clamping range. A wide range of accessories, for universal applications. The Execution DLS6i is due to their high rated breaking capacity of 10 kA is particularly suitable for use in industrial plants. Switch with the trigger characteristic B set the standard protection for light and socket outlet circuits are safely.
