Doepke 09981062 RH 063-300 Main RCCB 3-pin 63 A 240 V, 415 V
EAN:
Part number:
Item no:
Product type
Main RCCB
Number of pins
3
Nominal current - rounded value
63 A
Nominal voltage (details)
240 V<br>415 V
Nominal current
63 A
Datasheet (PDF)
Highlights & Details
DOEPKE main switch RH 063-300
- Quick mounting on DIN rail
- All mounting positions permitted
- Wide range of uses
Technical specifications
- Nominal voltage (details)
240 V
415 V
- Product type
Main RCCB
- Number of pins
3
- Nominal current - rounded value
63 A
- Nominal current
63 A
- Factory colour
Multicolour
- Dim
(W x H x D) 52 x 79 x 72 mm
- Content
1 pc(s)
- Duty class
gG
- Nominal voltage
240 V
415 V
- Width
52 mm
- Height
79 mm
- Depth
72 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2136329 Doepke 09981062 RH 063-300 Main RCCB 3-pin 63 A 240 V, 415 V
User & Safety Instructions
User & Safety Instructions 2136329 Doepke 09981062 RH 063-300 Main RCCB 3-pin 63 A 240 V, 415 V
Description
Load racing or switch disconnect electrical equipment or parts of the system completely and the poles of the electrical supply. Turn off even under load or overload. They are used to cut-off for maintenance work and system protection. The devices of the series RH are modular main circuit breaker switch with separating function and are characterized by high wear and tear resistance of the contacts. The design allows the use of a switching lock and corresponds to the international building codes. The devices of the series RH are universally applicable, for example in the industry and building technology or in the home.
This text is machine translated.
This text is machine translated.
Features
- High short-circuit resistance and high switching capacity
- Switch position indicator
- Quick-action switching function when switched on
- Double-sided double terminals for large conductor cross-section and busbar
Hints
The description of the devices of the series RH includes both the rated current (first number pair), as well as the earth (last number pair), in the order of nc, no and changer is listed. Thus has a "RH 063-300" such as a rated current of 63 A, 3 normally-open, but no opener or changeover contacts.
