Doepke HS25-40 Contactor 4 makers 230 V + auxiliary contact Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Contactor
No. of pins
4-pin
Nominal voltage
230 V
Packaging type
Piece
Type
HS25-40
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.04
3
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.04 / piece)
€ 26.04
plus VAT.
Only 2 Piece(s) available
Highlights & Details
DOEPKE protection HS 25-40
- Quick mounting on DIN rail
- All mounting positions permitted
Technical specifications
- Packaging type
Piece
- Product type
Contactor
- Type
HS25-40
- No. of pins
4-pin
- Contact type
4 makers
- Auxiliary contact type
4 makers
- Nominal voltage
230 V
- Control voltage (max.)
230 V AC
- Control voltage range
230 V AC (max)
- Switching voltage (max.)
230 V AC
- Max. switching capacity
25 VA
- Permanent current (max.)
25 A
- Features
+ auxiliary contact
- Mounting type
DIN rail
- Electrical lifespan
100 000
- Durability
150,000
IP20
- Width
36 mm
- Height
85 mm
- Depth
65 mm
- Dim
(W x H x D) 36 x 85 x 65 mm
- Content
1 pc(s)
- Weight
0.21
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2136297 Doepke HS25-40 Contactor 4 makers 230 V + auxiliary contact Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2136297 Doepke HS25-40 Contactor 4 makers 230 V + auxiliary contact Piece 1 pc(s)
Description
A protection is an electromagnetically operated remote switch for large electrical services. By means of a lower current, a large current can be switched. They guarantee galvanic isolation between the control circuit and after ignition circuit. Installation contactors of the series HS switch very quiet and are extremely brummarm. They are characterised by their long mechanical and electrical life. Your solenoid is suitable for continuous operation (100% duty cycle). Equipment in this design, with a control voltage of 230 V AC. Features: - large spectrum of different contacts; - high electrical and mechanical life; - extremely brummarm; - suitable auxiliary switch and sealing cap available mounting type: quick mounting on rail fixing - any installation position applications: installation contactors are versatile in living and purpose and industrial systems. You assume the switching from incandescent lamps, fluorescent lamps, transformers for low-voltage halogen lamps, mercury-vapor high-pressure lamps (HQL, HPL), metal halogen lamps (HQI, HPI), sodium, low and high-pressure lamps, storage oven or drives (motors). Notes: - the name of the devices of this series includes both the rated current (first number pair) as well as the earth (last number pair): A HS 25-31, for example a rated current of 25 A, three NC and one NO contact.; - in ambient temperatures from 40°C we recommend the use of spacer RD 05.
