Buy DSG Canusa 4500024032 High Temperature Heat Shrink Tubing 1 pc(s) N/A

A white, cylindrical bar running diagonally across the image, without visible details or background information.

Image similar

A yellow thermocouple with a metal plug at the end. It has a long, insulated cable used for temperature measurement.

Two electrical cables, one red and the other green, are bundled together in a transparent heat shrink tube.

1/3

Image similar

Nominal inside diameter (pre-shrinkage)

2.40 mm

Nominal diameter (post-shrinkage)

1.20 mm

Heatshrink features

Highly flame-retardant

Thin-walled

Content

1 pc(s)

Product type

Heatshrink w/o adhesive

Datasheet (PDF)

80 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Unit Price

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (1 m = € 2.96)

€

Report legal concerns

Highlights & Details

DSG Canusa 4500024032 High Temperature Heat Shrink Tubing 1 pc(s) N/A

2 : 1
-55 - +175 °C

Technical specifications

Shrink temperature + 175 °C
Elongation at break 450% according to IEC 60684-2
Breakdown voltage 31.5 kV/mm
Tensile strength: 50 MPa according to IEC 60684-2

Nominal inside diameter (pre-shrinkage): 2.40 mm

Nominal diameter (post-shrinkage): 1.20 mm

Factory colour: Transparent

Shrinkage: 2:1

Heatshrink features: Highly flame-retardant
Thin-walled

Content: 1 pc(s)

Material: Fluoropolymer (cross-linked)

Shrink temperature (min.): +175 °C

Min. temperature: -55 °C

Max. temperature: +175 °C

Manufacturer part #: 4500024032

Halogen-free: No

Type: 4500024032

Certification: UL VW-1 · CSA · VG 95343 part 5 Type F · MIL-DTL-23053/8

Temperature range: -55 - +175 °C

RoHS-compliant: Yes

Standards: UL VW-1 · CSA · VG 95343 part 5 Type F · MIL-DTL-23053/8

Product type: Heatshrink w/o adhesive

Documents & Downloads

Datasheet

Datasheet 529380 DSG Canusa 4500024032 High Temperature Heat Shrink Tubing 1 pc(s) N/A

User & Safety Instructions

User & Safety Instructions 529380 DSG Canusa 4500024032 High Temperature Heat Shrink Tubing 1 pc(s) N/A

Description

DERAY®-KY175 is a semi-rigid, thin-walled heat-shrink tubing made of Kynar®, ideally suited for all applications in the electronics and automobile industries as well as for military uses that require mechanical protection and must be visually inspected.
