Highlights & Details

EA Elektro Automatik 38917154 Rail mounted PSU (DIN) 0.83 A 10 W No. of outputs:1 x Content 1 pc(s)

AC input voltage AC: 90-264V
DC input voltage DC: 120-370V
Output power rating: 10W
Output voltage: 12 - 15V DC
Output current: 0.83A
Protection against overload and short-circuit
Overtemperature protection
Overvoltage protection
Natural cooling via convection
Protection degree IP20
Isolation class II
Safety EN 60950
EMC EN 61204 (EN 55022 class B)

Technical specifications

Nominal input voltage: 115 V/AC
230 V/AC
120 - 370 V/DC

Type: Switched Mode

Product type: Rail mounted PSU (DIN)

Min. input voltage: 90 V AC

Output voltage: 12 - 15 V DC

Inputs: 1

Input voltage: 90 - 264 Vac, 120 - 370 V DC

Input voltage (max.): 264 V AC

Max. output current: 0.83 A

Output current (max.) - rounded: 830 mA

: 10 W

Phases: 1

No. of outputs: 1 x

Connection: Screw terminal

Dim: (W x H x D) 23 x 91 x 57 mm

Weight: 70 g

Output voltage (max.): 15 V DC

Output voltage (min.): 12 V DC

Manufacturer part #: 38917154

Content: 1 pc(s)

Width: 23 mm

Height: 91 mm

Type: EA-PS 812-010 KSM

Depth: 57 mm

: 10 W

Connections: Screw terminals

Output current (details): 0.83 A

Documents & Downloads

Datasheet

Datasheet 512932 EA Elektro Automatik 38917154 Rail mounted PSU (DIN) 0.83 A 10 W No. of outputs:1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 512932 EA Elektro Automatik 38917154 Rail mounted PSU (DIN) 0.83 A 10 W No. of outputs:1 x Content 1 pc(s)

Description

Single-phase switched mode DIN rail power supply belonging to EA's PS 800 KSM series. Designed for mounting on DIN TS35/7.5 or DIN TS35/15 rails. Housed in a rugged plastic case with protection degree IP20.

This model has a wide input range for 90V to 264Vac or120V to 370Vdc for worldwide usage without the need of selecting the input. The unit is protected against short-circuit, overload, overtemperature and overvoltage.

The output is isolated against the mains supply (floating potential).
The output voltage is adjustable within 12 - 15V DC. The unit is provided with output current limiting to 110%-130% (overload) or 150% (short-circuit).

A derating of 2.5%/°C for temperatures of >55°C up to 70°C is required.
