Eaton 187449 PFIM-25/2/003-G/F RCCB for mixed frequency bands s 2-pin 25 A 0.03 A 230 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
2
Release characteristics
s
Differential current rating
0.03 A
Nominal current - rounded value
25 A
Datasheet (PDF)
Number
Total (€ 117.64 / piece)
€ 117.64
plus VAT.
Only 3 Piece(s) available
Technical specifications
- Connectable conductor cross-section multi-strand: 1.5 - 16 mm²
- connectable conductor cross-section single-strand: 1.5 - 35 mm²
- Product type
RCCB
- Number of pins
2
- Release characteristics
s
- Differential current rating
0.03 A
- Nominal current
25 A
- Nominal current - rounded value
25 A
- Dim
(L x W) 80 mm x 35 mm
- Model
for mixed frequency bands
- Factory colour
White
- Content
1 pc(s)
- Nominal voltage
230 V
- Width
35 mm
- Length
80 mm
- Depth
70.50 mm
- Weight
0
DIN rail
AC
70.5 mm
25 A
230 V
440 V
2
0.03 A
Other
FALSE
10 kA
3 kA
2
2
TRUE
7035
FALSE
50 Hz
IP20
1.5-35 mm²
1.5-16 mm²
TRUE
-25-55 °C
TRUE
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2234790 Eaton 187449 PFIM-25/2/003-G/F RCCB for mixed frequency bands s 2-pin 25 A 0.03 A 230 V
User & Safety Instructions
User & Safety Instructions 2234790 Eaton 187449 PFIM-25/2/003-G/F RCCB for mixed frequency bands s 2-pin 25 A 0.03 A 230 V
Description
· Type AC, A and F
· tripped display
· for fault and additional protection
· Real contact position display
· G version for high interference immunity
· Automatic restart possible
· S version for selectivity to subsequent FIS
· Complete range of compact fault current circuit breakers for residential and purpose-built
· Increased protection in applications with 1phasigen frequency converters through the Detection of mixed frequencies
· Higher failure strength thanks to delayed triggering and higher surge current strength> 3 kA
· Higher load capacity with smooth DC error currents up to 10 mA
This text is machine translated.
· tripped display
· for fault and additional protection
· Real contact position display
· G version for high interference immunity
· Automatic restart possible
· S version for selectivity to subsequent FIS
· Complete range of compact fault current circuit breakers for residential and purpose-built
· Increased protection in applications with 1phasigen frequency converters through the Detection of mixed frequencies
· Higher failure strength thanks to delayed triggering and higher surge current strength> 3 kA
· Higher load capacity with smooth DC error currents up to 10 mA
