Eaton 630NHG3BI-400 NH fuse Suitable for Fuse size 000 - 4 Fuse size = 3 630 A 400 V 3 pc(s)
EAN:
Part number:
Item no:
Product type
NH fuse
Fuse size
3
Nominal current - rounded value
630 A
Type
Insulated gripping tab
Content
3 pc(s)
Datasheet (PDF)
Number (Package size 3 pc(s))
Total (€ 24.65 / piece)
€ 73.94
plus VAT.
14-day return policy included
Technical specifications
- Type
Insulated gripping tab
- Product type
NH fuse
- Fuse size
3
- Content
3 pc(s)
- Nominal current
630 A
- Nominal current - rounded value
630 A
- Switch-off capacity
120 kA
- Duty class
gG
gL
- Nominal voltage
400 V
- Suitable for
Fuse size 000 - 4
AC
630 A
120 A
gL/gG (cable protection/equipment protection)
Combination fuse status indicator
400
36
TRUE
NH3
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2622431 Eaton 630NHG3BI-400 NH fuse Suitable for Fuse size 000 - 4 Fuse size = 3 630 A 400 V 3 pc(s)
User & Safety Instructions
User & Safety Instructions 2622431 Eaton 630NHG3BI-400 NH fuse Suitable for Fuse size 000 - 4 Fuse size = 3 630 A 400 V 3 pc(s)
Information
Information 2622431 Eaton 630NHG3BI-400 NH fuse Suitable for Fuse size 000 - 4 Fuse size = 3 630 A 400 V 3 pc(s)
Description
Dual display systemBussmann's patented dual display provides clear viewing and provides highly reliable local and remote* display. This reduces the time and cost of replacing fuse links.* Using an optional microswitchLow power lossBussmann's Low Watts Loss (low power loss) fuse links reduce overall operating costs and carbon emissions by reducing energy consumption and heat transfer to the equipment.Compliant with the law worldwideBussmann NH fuse links have been tested and are compliant with IEC 60269-1 and 2, DIN 43620, VDE, CE, CCC (China), RoHS and can be recycled to guarantee global acceptance.
