Eaton 63NHG000B NH fuse with blown fuse indicator Fuse size = 000 63 A 500 V 1 pc(s)
EAN:
Part number:
Item no:
Product type
NH fuse
Fuse size
000
Nominal current - rounded value
63 A
Type
Live grip bottles made of metal
RoHS-compliant
Yes
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.19
5
6% = € 0.24
€ 3.95
10
8% = € 0.34
€ 3.85
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.19 / piece)
€ 4.19
plus VAT.
14-day return policy included
Technical specifications
- Design of indicator: Combination indicator
- Type
Live grip bottles made of metal
- Product type
NH fuse
- Fuse size
000
- RoHS-compliant
Yes
- Dim
(W x H) 79.0000 mm x 51.0000 mm
- Content
1 pc(s)
- Nominal current
63 A
- Nominal current - rounded value
63 A
- Model
with blown fuse indicator
- Switch-off capacity
120 kA
- Duty class
gG
gL
- Nominal voltage
500 V
- Width
79.0000 mm
- Height
51.0000 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2306941 Eaton 63NHG000B NH fuse with blown fuse indicator Fuse size = 000 63 A 500 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2306941 Eaton 63NHG000B NH fuse with blown fuse indicator Fuse size = 000 63 A 500 V 1 pc(s)
Information
Information 2306941 Eaton 63NHG000B NH fuse with blown fuse indicator Fuse size = 000 63 A 500 V 1 pc(s)
Description
Dual display systemBussman's patented dual display provides a clear display and provides an extremely reliable local and remote* display. This reduces the time and cost of replacing backup operations.* Using an optional microswitchLow power lossBussmann's "Low Watts Loss" (low loss of current) fuse inserts reduce the general operating costs as well as carbon emissions through lower energy consumption and less heat transfer to the devices.Worldwide legal complianceBussmann NH fuse links have been tested and are compliant with IEC 60269-1 and 2, DIN 43620, VDE, CE, CCC (China), RoHS and can be recycled to guarantee global acceptance.
