Buy Ebara 1771051404A RIGHT 100 Effluent sump pump 18 m³/h 10.5 m

A silver stainless steel submersible pump with three black cables and a blue float switch, standing on a silver base.

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ebara RIGHT 100 submersible pump

Max. delivery head=10.5 m
Max. feed rate=18 m³/h
Operating voltage=400 V

Technical specifications

Product type: Effluent sump pump

Max. delivery head: 10.5 m

Max. feed rate: 18 m³/h

Max. discharge pressure: 1.05 bar

Operating voltage: 400 V

Max. size of solids: 35 mm

: IPX8

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2207195 Ebara 1771051404A RIGHT 100 Effluent sump pump 18 m³/h 10.5 m

Description

Submersible pumps for dirt and waste water made of stainless steel AISI 304
The submersible pumps made of stainless steel AISI 304 are suitable for the conveyance of dirt and waste water. Among the areas of application are waste water and waste water disposal with fibrous components and solids, drying of cellars, garages and commercial objects, emptying of pump shafts and containers for dirty water, leachate and rainwater, disposal of gray water also from commercial washing machines and dishwashers, plant/apparatus construction and industrial applications.

This text is machine translated.

Features

Max. Immersion depth 7 m with 10 m cable length
Max. Medium temperature 50°C.
Max. Solid size 35 mm (free ball passage)
Number of poles: 2
Insulation class F
Protection type IPX8
Three-phase current 3~400V ±10%
Pump housing AISI 304 (EN 1.4301)
Impeller AISI 304 (EN 1.4301)
Shaft AISI 303 (EN 1.4305)(Media contact part)
Mechanical seal
Coal/ceramic/NBR (motor side)
Silicon Carbide/Silicon Carbide/NBR (Pump Side)
With 10 m power cable H07RN-F, free cable end.
Three-phase version with integrated thermo-sensor cable for connection to an external motor protection
