econ connect MPL10/10R econ connect MPL10/10R N/A MPL10/10R Plug, straight Pins: 10 Clear 1 pc(s) MPL10/10R Plug, straig
EAN:
Part number:
Item no:
Connector type
Plug, straight
Connector standard
RJ48
Type
MPL10/10R
AWG max.
26
AWG (min.)
28
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.24
30
8% = € 0.02
€ 0.22
50
13% = € 0.03
€ 0.21
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.24 / piece)
€ 2.40
plus VAT.
Highlights & Details
econ connect MPL10/10R N/A MPL10/10R Plug, straight Pins: 10 Clear 1 pc(s)
Our service for you
Technical specifications
- Type
MPL10/10R
- Connector type
Plug, straight
- Connector standard
RJ48
- AWG max.
26
- AWG (min.)
28
- Connection
Cut & Clip
- Factory colour
Clear
- Content
1 pc(s)
- Contact material
Phosphorus bronze gold plated
- RoHS-compliant
Yes
- Seal type
Snap-in
- Material (details)
Polycarbonate
- Nominal current (details)
1.5 A
- Pins
10
- Temperature range
40 - 125 °C
Documents & Downloads
Datasheet
Datasheet 1311401 econ connect MPL10/10R econ connect MPL10/10R N/A MPL10/10R Plug, straight Pins: 10 Clear 1 pc(s) MPL10/10R Plug, straig
