econ connect Pin strip (precision) No. of rows: 1 Pins per row: 20 PAKSN20G2 1 pc(s)
EAN:
Part number:
Item no:
Connector type
Pin strip, straight
Product type
Pin strip (precision)
No. of rows
1
Total number of pins
20
CS
2.54 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
2
-
€ 1.50
6
7% = € 0.11
€ 1.39
10
11% = € 0.16
€ 1.34
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 2
Total (€ 1.50 / piece)
€ 3.00
plus VAT.
14-day return policy included
Highlights & Details
Straight header, pitch 2.54
- Content 1 pc(s)
- No. of rows 1
- Pins per row 20
Our service for you
Technical specifications
- Connector type
Pin strip, straight
- Product type
Pin strip (precision)
- No. of rows
1
- Pins per row
20
- Total number of pins
20
- CS
2.54 mm
- Connection
Print
- Factory colour
Black
- Pin shape
Circular
- Nominal voltage
500 V AC
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Contact surface
Gold plated
- Contact material
Copper alloy
- Case material
PBT
- Pin length (receptacle)
3 mm
- Pin length (PCB)
3.96 mm
- Separable
No
- Dim
(L x W x H) 50.80 x 11.96 x 2.54 mm
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
PAKSN20G2
- Industrial packaging
No
- Content
1 pc(s)
- Width
11.96 mm
- Height
2.54 mm
- Length
50.80 mm
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Type
PAKSN20G2
Documents & Downloads
Datasheet
Datasheet 1303481 econ connect Pin strip (precision) No. of rows: 1 Pins per row: 20 PAKSN20G2 1 pc(s)
