econ connect SIL socket (precision) No. of rows: 1 Pins per row: 8 SCS8AA3 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.37
30
8% = € 0.03
€ 0.34
50
14% = € 0.05
€ 0.32
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.37 / piece)
€ 3.70
plus VAT.
Highlights & Details
Socket strip series SCS RM 2.54 mm
- Content 1 pc(s)
- No. of rows 1
- Pins per row 8
Technical specifications
- Connector type
Power strip, straight
- No. of rows
1
- Pins per row
8
- Total number of pins
8
- CS
2.54 mm
- Connection
Print
- Factory colour
Black
- Pin shape
Circular
- Nominal voltage
60 V
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Contact surface
Tin plated
- Contact material
Copper alloy
- Case material
Polyester
- Pin Ø
0.60 mm
- Pin length (PCB)
2.80 mm
- Separable
No
- Dim
(L x W x H) 20.32 x 7.43 x 2.54 mm
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
SCS8AA3
- Content
1 pc(s)
- Height
2.54 mm
- Length
20.32 mm
- Width
7.43 mm
- Industrial packaging
No
- Type
SCS8AA3
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Product type
SIL socket (precision)
Documents & Downloads
Datasheet
Datasheet 1311451 econ connect SIL socket (precision) No. of rows: 1 Pins per row: 8 SCS8AA3 1 pc(s)
