econ connect WS8G Pin strip Total number of pins 8 No. of rows 2 1 pc(s)
EAN:
Part number:
Item no:
Product type
Pin strip
Total no. of pins
8
Connector type
Pin strip, straight
CS
2.54 mm
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.19
30
5% = € 0.01
€ 0.18
50
11% = € 0.02
€ 0.17
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.19 / piece)
€ 1.90
plus VAT.
Highlights & Details
Connector strip/trough
- No. of rows 2
- Content 1 pc(s)
Our service for you
Technical specifications
- Product type
Pin strip
- Total no. of pins
8
- Connector type
Pin strip, straight
- Connector orientation
Perpendicular (to the PCB)
- No. of rows
2
- CS
2.54 mm
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Pins per row
4
- Connection
Print
- Factory colour
Black
- Case material
PBT, UL94V-0
- Manufacturer part #
WS8G
- Content
1 pc(s)
- Contact material
Brass
- Width
17.76 mm
- Height
12 mm
- Length
9.05 mm
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Type
WS8G
- Dim
(L x W x H) 9.05 x 17.76 x 12 mm
- Nominal voltage
500 V AC
- Certification marks
DIN 41 651
- Number of pins
8
- RoHS-compliant
Yes
- Contact surface
Gold plated
Documents & Downloads
Datasheet
Datasheet 1303917 econ connect WS8G Pin strip Total number of pins 8 No. of rows 2 1 pc(s)
