Buy Einhell 4170742 GC-DP 1340 G Effluent sump pump 23000 l/h 10 m

Black and white photograph of a coiled rope.

A cross-section of a mechanical turbopump with visible components, including shaft and rotor, in a technical illustration.

Red motor with black cables and metal handles; close-up. The cables are attached at the top.

'Section of a metallic pump with black and red components.'

Silver, shiny metal component with red and black elements, possibly part of a machine or technical device.

A red Einhell submersible pump with cable and power socket.

Red drainage pump by Einhell with integrated float switch and black hose connection.

A red-painted machine displays large screws with a twisted design inside. The form resembles a turbine or pump.

1/9

Datasheet (PDF)

Unavailable

10 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Einhell Dirt water pump GC-DP 1340 G.

Double mechanical seal for a long life
Carrying handle, intake housing and motor housing made of stainless steel
Cast impeller

Technical specifications

Hose connection ca. 59.6 mm (G2) IG
Water temperature max. 35°C
Switching point height: A max. approx. 70 cm
Switching point height: from min. approx. 20 cm

Product type: Effluent sump pump

Max. delivery head: 10 m

Max. feed rate: 23000 l/h

Max. discharge pressure: 1 bar

Operating voltage: 230 V

Power consumption (P1): 1300 W

Pressure connection: 56.7 mm (2") IT

Max. size of solids: 40 mm

Immersion depth: 5 m

Max. cable length: 10 m

Float switch: Yes

Height: 530 mm

(Ø): 160 mm

Dim: (Ø x H) 160 mm x 530 mm

Weight: 19.3 kg

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1179259 Einhell 4170742 GC-DP 1340 G Effluent sump pump 23000 l/h 10 m

User & Safety Instructions

User & Safety Instructions 1179259 Einhell 4170742 GC-DP 1340 G Effluent sump pump 23000 l/h 10 m

Warranty Terms

Warranty Terms 1179259 Einhell 4170742 GC-DP 1340 G Effluent sump pump 23000 l/h 10 m

Description

The waste water pump GC-DP 1340 G is a robust, extremely powerful and reliable tool for the highest demands and hardest uses when pumping empty ponds, wells, excavation pits, flooded cellars and much more. With a power consumption of 1,300 watts, the power pack delivers up to 23,000 liters of contaminated water per hour. The high-quality double mechanical seal ensures a long service life and extensive maintenance-free operation. The upper and lower housing parts and the GC-DP 1340 G cast pump wheel are made of solid cast steel, the suction housing and the motor housing are made of corrosion-resistant stainless steel. Your infinitely height-adjustable float switch allows you to choose between continuous operation and a pre-selected switch-on and switch-off level. The G2 hose connection is designed for 2" hoses (approx. 50.8 mm). A convenient carrying handle enables the comfortable transport of the dirty water pump. The delivery includes a 6 meter long rope for draining the pump into the pond/well.

This text is machine translated.

Features

HandleContinuously adjustable float switchDouble mechanical seal for long service lifeHousing top and bottom, castStainless steel suction /motor housingCast pump wheelIncl. 6 m ropeHose connection for approx. 50.8 mm (2")
