Name: EIZO ColorEdge CG2400SV LCD EEC E (A - G) 61.2 cm (24.1 inch) 1920 x 1080 p 16:10 11 ms IPS LCD
Brand: EIZO
SKU: 3843182

Highlights & Details

EIZO ColorEdge CG2400SV LCD

Screen size 61.2 cm (24.1 inch) WUXGA, 1920 x 1080 p;Response time: 11 msEnergy efficiency rating (calc): E (A - G)
Interfaces: Tiltable

Technical specifications

Screen technology: LCD
Contrast ratio: 1800:1
0.27 x 0.27 mm pixel distance
Pixel density: 94 ppi
Market positioning: Graphic design
Swivel angle range 0 - 344 °
Tilt angle range -5 - 35°
Energy efficiency rating (SDR): Not available (A - G)
Energy efficiency rating (HDR): Not available

Product type: LCD

Resolution (max.): 1920 x 1080 p

Screen size diagonal (cm): 61.1 cm

Screen size diagonal (inches): 24.1 inch

Screen size diagonal (inches): 24 inch

Image format: 16:10

Panel technology: IPS LCD

Touchscreen (display): No

Frame rate: 60 Hz

Response time: 11 ms

Brightness: 400 cd/m²

Factory colour: Black

No. of DisplayPort: 1 x

No. of HDMI ports: 1 x

Features: Tiltable

Power consumption (standby): 0.5 W

Hor. viewing angle: 178°

Vertical viewing angle: 178°

HDR support: Yes

Width: 554.4 mm

Height: 408.1 mm

Depth: 245 mm

Weight: 8.5 kg

Power supply (details): 100-240 V

Dim: (W x H x D) 554.4 x 408.1 x 245 mm

Display size: 24 inch - 29 inch

Display type: 16:10

Display resolution mode: WUXGA

: E (A - G)

Display: 61.2 cm (24.1 inch)

Screen resolution: Full HD (1920 x 1080 Pixel)

Display (cm): 61.2 cm

Power consumption (ON): 18 W

Device depth (without stand): 70.2 mm

Display properties: IPS

Display resolution: 1920 x 1200 Pixel

HDCP: Yes

Height (without base): 374.1 mm

: 100 x 100 mm

Anti-glare screen: yes

Stand included: yes

Operating temperature (T-T): 0 - 35 °C

Headphone out: yes

Weight (without stand): 5.5 kg

Width (without stand): 554.4 mm

Storage relative humidity (H-H): 10 - 90 %

Colour depth: 10 Bit

VESA mounting: yes

Height adjustment: yes

NVIDIA G-SYNC: no

Built-in USB hub: yes

Number of upstream ports: 2

USB Type-A downstream ports quantity: 4

Built-in speaker(s): no

Adjustable height (max): 15.5 cm

Pivot: yes

Digital horizontal frequency: 26 - 76 kHz

Digital vertical frequency: 23 - 61 Hz

sRGB coverage (typical): 100 %

Adobe RGB coverage: 97 %

AMD FreeSync: no

On Screen Display (OSD): yes

Flicker-free technology: yes

Sun hood included: yes

Quick start guide: yes

DCI-P3 coverage: 99 %

Number of USB Type-B upstream ports quantity: 2

Hardware calibration: yes

Built-in calibration sensor: yes

: 16

HDMI: yes

LED backlight: yes

Operating relative humidity (H-H): 20 - 80 %

Swivelling: yes

Storage temperature (T-T): -20 - 60 °C

Pivot angle: -90 - 90°

Built-in camera: no

Tilt adjustment: yes

Viewable size, horizontal: 51.8 cm

Power consumption (max): 64 W

Viewable size, vertical: 32.4 cm

Built-in KVM switch: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3843182 EIZO ColorEdge CG2400SV LCD EEC E (A - G) 61.2 cm (24.1 inch) 1920 x 1080 p 16:10 11 ms IPS LCD

Description

With compact 24", SDI connectivity and HDR support, the ColorEdge CG2400SV is the ideal monitor for editing, studios and mobile productions in the film and broadcast industry. The SDI input and output (3G-SDI level A and HDSDI) enables lossless transmission of uncompressed video signals ś perfect for use with camera systems and live feeds. HDMI and DisplayPort are also available. With a maximum brightness of 400 cd/m² and a contrast ratio of 1800:1, the CG2400SV meets the requirements of the DCI standard. Support for HLG and PQ gamma curves ensures accurate HDR representation - Ideal for post production and monitoring on set. The wide gamut IPS panel covers 98% of the DCI-P3 color space and supports the BT.2020 standard. With 10-bit display and a 16-bit 3D LUT, the monitor delivers accurate color reproduction and soft transitions - indispensable for color-critical applications. The integrated calibration sensor allows effortless automatic calibration. With the function Pixel Inspection, users can directly check that signal processing is set correctly throughout the entire workflow. The integrated USB-hub, the headphone connection and the accompanying light shield completes the lavish equipment of the CG2400SV.

This text is machine translated.

Features

24" Wide-Gamut LCD with 1920 x 1200 pixels, 16:10-format
SDI input and output (3G-SDI level A and HD-SDI)
Wide color gamut: 98% DCI-P3 color room coverage
400 cd/m² maximum brightness, contrast 1800:1
10-bit display, 16-bit 3D look-up table
Precise hardware calibration of brightness, white point and gamma
Built-in calibration sensor ensures automatic self calibration
Digital Uniformity equalizer for perfect light density distribution and color purity
Control of the color signal by Pixel Inspection
DisplayPort and HDMI input and headphone jack
Light protection hood included in delivery
