Name: EIZO ColorEdge LCD EEC F (A - G) 61.2 cm (24.1 inch) 1920 x 1200 p 16:10 14 ms IPS LCD
Brand: EIZO
SKU: 3765857

Highlights & Details

EIZO ColorEdge LCD

Screen size 61.2 cm (24.1 inch) WUXGA, 1920 x 1200 p;Response time: 14 msEnergy efficiency rating (calc): F (A - G)
Interfaces: Pivoted, Height adjustable, Tiltable, Swivelling, VESA Mount 100 x 100 mm

Technical specifications

Screen technology: LCD
Contrast ratio: 1000:1
0.27 x 0.27 mm pixel distance
Pixel density: 94 ppi
Market positioning: Photo processing
Swivel angle range 0 - 344 °
Tilt angle range -5 - 35°
Energy efficiency rating (HDR): Not available

Product type: LCD

Resolution (max.): 1920 x 1200 p

Screen size diagonal (cm): 61.1 cm

Screen size diagonal (inches): 24.1 inch

Screen size diagonal (inches): 24 inch

Image format: 16:10

Panel technology: IPS LCD

Touchscreen (display): No

Frame rate: 60 Hz

Response time: 14 ms

Brightness: 300 cd/m²

Static contrast ratio: 1000 : 1

Factory colour: Black

No. of DisplayPort: 1 x

No. of HDMI ports: 1 x

Features: Pivoted
Height adjustable
Tiltable
Swivelling
VESA Mount 100 x 100 mm

Inclination: -5/+35

Adjustable height: 155 mm

Power consumption (standby): 0.3 W

Hor. viewing angle: 178°

Vertical viewing angle: 178°

Curved monitor: No

Width: 554 mm

Height: 396 mm

Depth: 245 mm

Weight: 8.1 kg

Power supply (details): 100 - 240 V

Dim: (W x H x D) 554 x 396 x 245 mm

Screen size/position settings: Height
Tilt
Pivoting (rotation)
Pivoting

Display size: 24 inch - 29 inch

Display type: 16:10

Display resolution mode: WUXGA

Wall mounting option: 100 x 100 mm VESA standard

: F (A - G)

Display: 61.2 cm (24.1 inch)

Screen resolution: WUXGA (1920 x 1200 Pixel)

Display (cm): 61.2 cm

Power consumption (off): 0.3 W

Power consumption (ON): 15 W

Device depth (without stand): 64 mm

Display properties: IPS

Display resolution: 1920 x 1200 Pixel

HDCP: Yes

Charging method (Power Delivery): with USB Power Delivery

Height (without base): 362 mm

Type: internal

: 100 x 100 mm

UKCA: yes

Anti-glare screen: yes

Stand included: yes

Operating temperature (T-T): 0 - 35 °C

Weight (without stand): 5.1 kg

Width (without stand): 554 mm

Cable lock slot: yes

Storage relative humidity (H-H): 10 - 90 %

Colour depth: 10 Bit

VESA mounting: yes

Height adjustment: yes

Power consumption (PowerSave): 0.3 W

NVIDIA G-SYNC: no

Built-in USB hub: yes

Number of upstream ports: 2

USB Type-A downstream ports quantity: 4

Built-in speaker(s): no

Adjustable height (max): 15.5 cm

Pivot: yes

sRGB coverage (typical): 100 %

AMD FreeSync: no

On Screen Display (OSD): yes

USB Type-C DisplayPort Alternate Mode: yes

Horizontal scan range: 15 - 76 kHz

Flicker-free technology: yes

USB Power Delivery up to: 70 W

Quick start guide: yes

Number of USB Type-C upstream ports quantity: 1

Number of USB Type-B upstream ports quantity: 1

Energy consumption (SDR) per 1000 hours: 19 kWh

Hardware calibration: yes

: 16

HDMI: yes

LED backlight: yes

Operating relative humidity (H-H): 20 - 80 %

Swivelling: yes

Storage temperature (T-T): -20 - 60 °C

Number of OSD languages: 6

Pivot angle: 0 - 90°

Built-in camera: no

Tilt adjustment: yes

Vertical scan range: 23 - 61 Hz

Viewable size, horizontal: 51.8 cm

Power consumption (max): 134 W

Viewable size, vertical: 32.4 cm

Built-in KVM switch: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3765857 EIZO ColorEdge LCD EEC F (A - G) 61.2 cm (24.1 inch) 1920 x 1200 p 16:10 14 ms IPS LCD

Description

The ColorEdge CS2400R is the cheapest entry into the world of maximum precision: The panel offers a complete coverage of the sRGB and REC 709 color spaces. The Digital Uniformity Equalizer (DUE) provides for a homogeneous image display and the 16-bit look-up table guarantees absolutely precise color display with up to 10 bits. Through the exact factory calibration highest precision "out of the box" is guaranteed on one hand. On the other hand, the regularly recommended re-calibration is done in no time at all. In this way, photographers, film makers or picture workers can always rely on their monitor to show them an absolutely precise view of their image file. Docking functions via USB-C allows you to transfer the video signal with just one cable and power to the USB hub of the monitor. In addition, a mobile device can be supplied with up to 70 watt charging current. Thus the CS2400R becomes the central dock of the creative workflow with one hand. Alternatively, the monitor can also be operated via HDMI or DisplayPort and USB-B-Upstream.24"-Wide Gamut LCD with 1920 x 1200 pixels, 16:10-format

This text is machine translated.

Features

24"-IPS-LCD with 1920 x 1200 pixels, 16:10-format
100% color room cover for sRGB and REC 709
300 cd/m² maximum brightness, contrast 1000:1
10-bit display, 16-bit look-up table
Precise hardware calibration of brightness, white point and gamma
Digital Uniformity Equalizer for perfect light density distribution and color purity
USB-C (DisplayPort signal and up to 70 watt Power delivery), DisplayPort and HDMI input
USB hub with two 5Gbps (USB 3) and two USB 2 downstream ports
