EIZO FlexScan LCD EEC B (A - G) 61.2 cm (24.1 inch) 1920 x 1200 p 16:10 5 ms IPS LCD
EAN:
Part number:
Item no:
Highlights & Details
EIZO FlexScan LCD
- Screen size 61.2 cm (24.1 inch) WUXGA, 1920 x 1200 p;Response time: 5 msEnergy efficiency rating (calc): B (A - G)
- Interfaces: Built-in speakers, Pivoted, Swivelling, Tiltable, Height adjustable
Technical specifications
- Screen technology: LCD
- Contrast ratio 1300:1
- 0.27 x 0.27 mm pixel distance
- Pixel density: 94 ppi
- Swivel angle range 0 - 344 °
- Tilt angle range -5 - 35°
- Product type
LCD
- Resolution (max.)
1920 x 1200 p
- Screen size diagonal (cm)
61.1 cm
- Screen size diagonal (inches)
24.1 inch
- Screen size diagonal (inches)
24 inch
- Image format
16:10
- Panel technology
IPS LCD
- Touchscreen (display)
No
- Frame rate
60 Hz
- Response time
5 ms
- Brightness
350 cd/m²
- Static contrast ratio
1300 : 1
- Factory colour
Black
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- No. of VGA ports
1 x
- Features
Built-in speakers
Pivoted
Swivelling
Tiltable
Height adjustable
- Audio power (max.)
2 W
- Inclination
-5/+35
- Adjustable height
130 mm
- Power consumption (standby)
0.5 W
- Hor. viewing angle
178°
- Vertical viewing angle
178°
- Curved monitor
No
- Width
531 mm
- Height
358.4 mm
- Depth
233 mm
- Weight
6 kg
- Power supply (details)
100 - 240 V
- Dim
(W x H x D) 531 x 358.4 x 233 mm
- Screen size/position settings
Height
Tilt
Pivoting (rotation)
Pivoting
- Display size
24 inch - 29 inch
- Display type
16:10
- Range of uses
Office
- Display resolution mode
WUXGA
- Wall mounting option
100 x 100 mm VESA standard
B (A - G)
- Display
61.2 cm (24.1 inch)
- Screen resolution
WUXGA (1920 x 1200 Pixel)
- Display (cm)
61.2 cm
- Power consumption (off)
0 W
- Power consumption (ON)
8 W
- Device depth (without stand)
57 mm
- Display properties
IPS
- Display resolution
1920 x 1200 Pixel
- HDCP
Yes
- Height (without base)
345.2 mm
100 x 100 mm
- UKCA
yes
- Number of speakers
2
- Anti-glare screen
yes
- Stand included
yes
- Operating temperature (T-T)
5 - 35 °C
- Headphone out
yes
- Weight (without stand)
3.9 kg
- Width (without stand)
531 mm
- Cable lock slot
yes
- Storage relative humidity (H-H)
10 - 90 %
- VESA mounting
yes
- Height adjustment
yes
- NVIDIA G-SYNC
no
- Built-in USB hub
yes
- Number of upstream ports
1
- USB Type-A downstream ports quantity
4
- Headphone outputs
1
- DVI port
yes
- Built-in speaker(s)
yes
- Adjustable height (max)
13 cm
- Pivot
yes
- DVI-D ports quantity
1
- AMD FreeSync
no
- On Screen Display (OSD)
yes
- Horizontal scan range
31 - 76 kHz
- Flicker-free technology
yes
- Low Blue Light technology
yes
- Quick start guide
yes
- Number of USB Type-B upstream ports quantity
1
- Energy consumption (SDR) per 1000 hours
8 kWh
10
- HDMI
yes
- LED backlight
yes
- Operating relative humidity (H-H)
20 - 80 %
- Swivelling
yes
- Storage temperature (T-T)
-20 - 60 °C
- Pivot angle
-90 - 90°
- Built-in camera
no
- Automatic brightness control
yes
- Tilt adjustment
yes
- Vertical scan range
59 - 61 Hz
- Viewable size, horizontal
51.8 cm
- Power consumption (max)
54 W
- Viewable size, vertical
32.4 cm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3765865 EIZO FlexScan LCD EEC B (A - G) 61.2 cm (24.1 inch) 1920 x 1200 p 16:10 5 ms IPS LCD
Description
The FlexScan EV2410R convinces as a flexible all-rounder and is suitable Ideal for the classic office workplace. It is an indispensable tool on any desk and allows efficient working, energy-saving, eye-friendly and ergonomic. It has an IPS panel and horizontal and vertical 178° viewing angle as well as a resolution of 1920 x 1200 pixels. The low-reflection surface as well as brightness and contrast provides for a highly detailed and excellent image reproduction. Auto EcoView automatically adjusts the brightness to the ambient light in order to avoid blinding and to protect the eyes. Four inputs for digital and analogue signals, a USB hub as well as headphone and audio connections provide versatile connectivity. Due to the thin edge of the housing the monitor appears very compact and is particularly suitable for multi-screen operation. The associated software Screen InStyle enables a simple operation over a computer or network in addition to the screen menu.
This text is machine translated.
This text is machine translated.
Features
- 24"-office monitor in the 16:10-format with ergonomic and space-saving design
- DisplayPort, HDMI, DVI-D and D-Sub input for digital and analogue connection
- Contrast 1300:1, brightness 350 cd/m²
- Auto EcoView, EcoView Index and EcoView Optimizer for maximum power saving and optimum ergonomics
- 5 Gbps USB hub with one up and four downstream ports
- Proven environment-conscious and socially responsible production
- Available in black or white housing
Scope of delivery
- Cable
- Quick guide.
