Elmeko TLR 400 Speed limiter White
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
- With microcontroller and digital display for
- Temperature and error message
- Suitable for all single-phase AC motors up to 400W
- Temperature-dependant continuous adjustment
- Speed control for fans and
- Heat Exchangers
- Reduction of the noise level
- Energy saving
- Easy programming of
- Temperature setpoint, minimum and
- Maximum speed
- Alarm in case of overtemperature, sensor break
- And fan failure
- Scope of delivery: Speed controller in the
- Housing, with external digital sensor
- This text is machine translated.
Technical specifications
- Speed control: By phase angle
- Temperature range: -20°C ... +60°C
- Display: 4 digit LED 7 segment
- Temperature sensor: digital, resolution 0.5°C Fuse: 3.15 A quick fix: 35 mm DIN rail
- Product type
Speed limiter
- Operating voltage
230 V AC
- Content
1 pc(s)
400 W
- Factory colour
White
- Dim
(L x W) 96 mm x 70.5 mm
- Width
70.5 mm
- Length
96 mm
- UKCA
yes
