ELSO 735230 ELSO system power supply 735230 with MEDIOPT CARE battery PSU ELSO 1 pc(s)

MEDIOPT care Uninterruptible DC power supply. Output current 20 A, input voltage 24V DC (20-28V DC). Output voltage: 24V DC (19-28V DC depending on operating status). Back-up time: 1 minute, 5 minutes, unlimited (adjustable). Battery charging current: Depending on power supply unit. Switching time: None, relay contacts: Battery operation Battery reserve, battery reserve: Signalling when the battery voltage drops to about 20% residual charge. Power cut-off: By opening an external contact, recharging time: Approx. 8 hours after deep discharge, switching threshold: 25.5 V 1.5%, connection control signals: Pluggable screw terminal 12-pin, connection load/power supply: Plug-in screw terminal 6-pin. Connection of additional battery: Pluggable screw terminal 4-pin, power supply: Adjustable 26-28V DC (nominal value 27.2). Deep discharge protection: At approx. 20V DC on the BATTERY, LED display: Integrated (see signal), operating environment: Temperature 0 40° C. Dimensions (WxHxD): 170 mmx135 mmx205mm, weight: 6.9 kg.

This text is machine translated.
