Emko ecoLITE.4.5.1R.0.0 Temperature controller Pt100, J, K, R, S, T, L -199 up to +999 °C 5 A relay (L x W x H) 90 x 48
EAN:
Part number:
Item no:
Product type
Temperature controller
Operating voltage
230 V AC
Max. temperature reading
+999 °C
Outputs (thermostats)
5 A relay
No. of relay outputs
1
Datasheet (PDF)
Number
Total (€ 105.03 / piece)
€ 105.03
plus VAT.
Only 5 Piece(s) available
Highlights & Details
EcoLITE temperature controller
- 3-digit actual value display
- 4-digit setpoint display
- Two-step controller
- Type J, K, R, S sensor input and Pt100 resistance thermometer
- Can be set to heating or cooling function
- Offset
- Hysteresis
- Password protection
Technical specifications
- Product type
Temperature controller
- Type
ecoLITE.4.5.1R.0.0
- Operating voltage
230 V AC
- Reading range
-199 up to +999 °C
- Max. temperature reading
+999 °C
- Min. temperature reading
-199 °C
- Outputs (thermostats)
5 A relay
- No. of relay outputs
1
- Dim
(L x W x H) 90 x 48 x 48 mm
- Factory colour
Black
- Height
48 mm
- Length
90 mm
- Width
48 mm
Front: IP65 / connection: IP20
- Sensor type
Pt100
J
K
R
S
T
L
- Manufacturer part #
ecoLITE.4.5.1R.0.0
- Mounting type
Recess-mount
- Weight
150 g
Documents & Downloads
Datasheet
Datasheet 2352493 Emko ecoLITE.4.5.1R.0.0 Temperature controller Pt100, J, K, R, S, T, L -199 up to +999 °C 5 A relay (L x W x H) 90 x 48
User & Safety Instructions
User & Safety Instructions 2352493 Emko ecoLITE.4.5.1R.0.0 Temperature controller Pt100, J, K, R, S, T, L -199 up to +999 °C 5 A relay (L x W x H) 90 x 48
Description
The Ecolite temperature controller is a two-point temperature controller used for heating or cooling applications. The universal sensor input is set in the programming to sensor type J, K, R, S or resistance thermometer Pt100 as required. Furthermore, the temperature controller has adjustment options such as offset, hysteresis, switching delay and much more. The large digits of the display allow easy reading of the values.
