Enda SSR EPAA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
90 V AC
Control voltage (max.)
240 V AC
Switching voltage (max.)
460 V AC
Current load (max.)
40 A
Datasheet (PDF)
Number
Total (€ 36.97 / piece)
€ 36.97
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Enda EPAA1-440Z semi-conductor relay 40A
- 40A AC-load current
- 480 V AC load voltage
- 90–240 VAC input voltage
- LED display for input voltage
- Switches at zero-crossing/random continuity of the alternating voltage
- Applicable for three-phase loads
- Varistor protection for peak voltages
- CE-labeled according to EN standards
Technical specifications
- Integrated varistor protection
- Insulation voltage: 2500V between I/O connections for 1min.
- Mains frequency: 50/-60Hz.
- Housing: Self-extinguishing plastic
- Product type
SSR
- Type
EPAA1-440Z
- Connection
Screw terminal
- Control voltage (min.)
90 V AC
- Control voltage (max.)
240 V AC
- Control voltage range
90 - 240 V AC
- Control current (max.)
8 mA
- Surge current (max.)
400 A
- Switching voltage (min.)
50 V AC
- Switching voltage (max.)
460 V AC
- Current load (max.)
40 A
- Output voltage (min.)
50 V
- Output voltage (max.)
460 V
- Max. output current
40 A
- Min. temperature
-25 °C
- Max. temperature
60 °C
IP20
- Width
45 mm
- Height
62 mm
- Depth
31 mm
- Weight
95 g
- Industrial packaging
Yes
- Permanent current (max.)
40 A
- Content
1 pc(s)
- Nominal control voltage
90 V AC
240 V AC
Documents & Downloads
Datasheet
Datasheet 3527735 Enda SSR EPAA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527735 Enda SSR EPAA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
Description
The model EPAA1-440Z is a single-pole solid-state relay (EPAA1) with 90-240V AC input voltage, 50-460V AC load voltage, 40A load current and zero-through switching.
