Enda SSR EPAA3-440Z 40 A Switching voltage (max.): 480 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
75 V AC
Control voltage (max.)
240 V AC
Switching voltage (max.)
480 V AC
Current load (max.)
40 A
Datasheet (PDF)
Number
Total (€ 88.23 / piece)
€ 88.23
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Enda EPAA3-440Z-T (3 X 40A) three-phase SSR
- Three phases
- 8-30 V AC/DC INPUT VOLTAGE
- 50-480 V AC load voltage
- LED display for input voltage
- Switches with the zero-crossing of the alternating voltage
- Applicable for three-phase loads
- Varistor protection for peak voltages
- Fan control thermostat
- CE-labeled according to EN standards
Technical specifications
- Fan control thermostat
- Built-in varistor protection
- Insulation voltage 2500Vrms
- Frequency 50°60Hz
- Product type
SSR
- Type
EPAA3-440Z
- Connection
Screws
- Control voltage (min.)
75 V AC
- Control voltage (max.)
240 V AC
- Control voltage range
75 - 240 V AC
- Control current (max.)
8 mA
- Surge current (max.)
400 A
- Switching voltage (min.)
50 V AC
- Switching voltage (max.)
480 V AC
- Current load (max.)
40 A
- Output voltage (min.)
50 V
- Output voltage (max.)
480 V
- Max. output current
40 A
- Min. temperature
-25 °C
- Max. temperature
60 °C
IP20
- Width
103 mm
- Height
74 mm
- Depth
37 mm
- Weight
200 g
- Industrial packaging
Yes
- Electrical lifespan
Very long
- Permanent current (max.)
40 A
- Content
1 pc(s)
- Nominal control voltage
90 V AC
240 V AC
Documents & Downloads
Datasheet
Datasheet 3527745 Enda SSR EPAA3-440Z 40 A Switching voltage (max.): 480 V AC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527745 Enda SSR EPAA3-440Z 40 A Switching voltage (max.): 480 V AC 1 pc(s)
Description
Enda EPAA3-440Z-T is a three-phase solid state relay (SSR) with AC control, zero-passage switching and integrated thermostat for fan control.
