Enda SSR EPDA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
6 V AC
6 V DC
Control voltage (max.)
30 V AC
30 V DC
Switching voltage (max.)
460 V AC
Current load (max.)
40 A
Datasheet (PDF)
Number
Total (€ 27.72 / piece)
€ 27.72
plus VAT.
Only 4 Piece(s) available
Highlights & Details
Enda EPDA1-440Z semi-conductor relay 40A
- Single phase
- 8–30 V AC/DC INPUT VOLTAGE
- 50–480 V AC load voltage
- LED display for input voltage
- Switches at zero-crossing/random continuity of the alternating voltage
- Applicable for three-phase loads
- Varistor protection for peak voltages
- CE-labeled according to EN standards
- This text is machine translated.
Technical specifications
- Zero cross (zero crossing)
- Switching function
- Built-in varistor protection
- Insulation voltage: 2500Vrms between I/O connections for 1 min.
- Load voltage 50−460V AC
- Product type
SSR
- Type
EPDA1-440Z
- Connection
Screw terminal
- Control voltage (min.)
6 V AC
6 V DC
- Control voltage (max.)
30 V AC
30 V DC
- Control voltage range
6, 6 - 30, 30 V AC, V DC
- Control current (max.)
17 mA
10 mA
- Surge current (max.)
400 A
- Switching voltage (min.)
50 V AC
- Switching voltage (max.)
460 V AC
- Current load (max.)
40 A
- Output voltage (min.)
50 V
- Output voltage (max.)
460 V
- Max. output current
40 A
- Min. temperature
-25 °C
- Max. temperature
60 °C
IP20
- Width
45 mm
- Height
62 mm
- Depth
31 mm
- Weight
95 g
- Industrial packaging
Yes
- Permanent current (max.)
40 A
- Content
1 pc(s)
- Nominal control voltage
8 V AC
8 V DC
30 V AC
30 V DC
Documents & Downloads
Datasheet
Datasheet 3527739 Enda SSR EPDA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527739 Enda SSR EPDA1-440Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
Description
Scope of delivery
- EPDA1-440Z semi-conductor relay
