Enda SSR ERAA1-240Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
90 V AC
Control voltage (max.)
240 V AC
Switching voltage (max.)
460 V AC
Current load (max.)
40 A
Datasheet (PDF)
Number
Total (€ 47.05 / piece)
€ 47.05
plus VAT.
Highlights & Details
Enda ERAA1-240Z SSR SSR solid-state relay for rail mounting
- 40 A AC load current
- 480 V AC load voltage
- 90–240 VAC input voltage
- LED display for input voltage
- Switches with the zero-crossing of the alternating voltage
- Applicable for three-phase loads
- Varistor protection for peak voltages
- CE-labeled according to EN standards
Technical specifications
- Frequency 50°60Hz
- Switch-on time Maximum 1 period
- Switch-off time Maximum 2 periods
- Insulation voltage 2500V.
- Product type
SSR
- Type
ERAA1-240Z
- Connection
Terminal strip
- Control voltage (min.)
90 V AC
- Control voltage (max.)
240 V AC
- Control voltage range
90 - 240 V AC
- Control current (max.)
8 mA
- Surge current (max.)
400 A
- Switching voltage (min.)
50 V AC
- Switching voltage (max.)
460 V AC
- Current load (max.)
40 A
- Output voltage (min.)
50 V AC
- Output voltage (max.)
460 V AC
- Max. output current
40 A
- Min. temperature
-25 °C
- Max. temperature
60 °C
IP20
- Width
30 mm
- Height
84 mm
- Depth
115 mm
- Weight
203 g
- Industrial packaging
Yes
- Electrical lifespan
Almost unlimited
- Permanent current (max.)
40 A
- Content
1 pc(s)
- Nominal control voltage
90 V AC
240 V AC
Documents & Downloads
Datasheet
Datasheet 3527751 Enda SSR ERAA1-240Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527751 Enda SSR ERAA1-240Z 40 A Switching voltage (max.): 460 V AC 1 pc(s)
Description
Semiconductor relay with integrated heatsinks.
This text is machine translated.
This text is machine translated.
Scope of delivery
- SSR EAA1-240Z
