Enda SSR ERDA1-240Z 40 A Switching voltage (max.): 320 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
6 V AC
6 V DC
Control voltage (max.)
30 V AC
30 V DC
Switching voltage (max.)
320 V AC
Current load (max.)
40 A
Datasheet (PDF)
Number
Total (€ 33.61 / piece)
€ 33.61
plus VAT.
Only 3 Piece(s) available
Highlights & Details
Enda ERDA1-240Z rail mounting SSR 40A
- 40 A AC load current
- 320 V AC load voltage
- 8–30 V AC/DC INPUT VOLTAGE
- LED display for input voltage
- Switches with the zero-crossing of the alternating voltage
- Applicable for three-phase loads
- Varistor protection for peak voltages
- CE-labeled according to EN standards
Technical specifications
- Integrated heat sink
- Built-in varistor protection
- Insulation voltage 2500Vrms
- Frequency 50°60Hz
- Product type
SSR
- Type
ERDA1-240Z
- Connection
Terminal strip
- Control voltage (min.)
6 V AC
6 V DC
- Control voltage (max.)
30 V AC
30 V DC
- Control voltage range
6, 6 - 30, 30 V AC, V DC
- Control current (max.)
17 mA
10 mA
- Surge current (max.)
400 A
- Switching voltage (min.)
24 V AC
- Switching voltage (max.)
320 V AC
- Current load (max.)
40 A
- Output voltage (min.)
24 V AC
- Output voltage (max.)
320 V AC
- Max. output current
40 A
- Min. temperature
-25 °C
- Max. temperature
60 °C
IP20
- Width
30 mm
- Height
84 mm
- Length
115 mm
- Weight
280 g
- Industrial packaging
Yes
- Permanent current (max.)
40 A
- Content
1 pc(s)
- Nominal control voltage
8 V AC
8 V DC
30 V AC
30 V DC
Documents & Downloads
Datasheet
Datasheet 3527747 Enda SSR ERDA1-240Z 40 A Switching voltage (max.): 320 V AC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527747 Enda SSR ERDA1-240Z 40 A Switching voltage (max.): 320 V AC 1 pc(s)
Description
Enda ERDA1-240Z is a single-phase solid state relay (SSR) with integrated heat sink for DIN rail mounting. It uses DC/AC control and zero-voltage switching.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Enda ERDA1-240Z
