Endress+Hauser Vibronic level gauge Capacitive FTM20 FTM20-AN23A PNP
EAN:
Part number:
Item no:
Product type
Vibronic level gauge
Max. operating voltage
45 V DC
Contact type
1 PNP
Outputs
PNP
Model
Capacitive
Number
Total (€ 394.12 / piece)
€ 394.12
plus VAT.
14-day return policy included
Highlights & Details
Vibron limit switches SoliANT FTM2x FTM20-AN23A FEM22; 3-conductor PNP 10-45VDC thread ANSI NPT1-1/2, 316L F16 polyester IP66/67 NEMA4X; NPT1/2 thread
- Approval: Ex-free range
- Process connection: ANSI NPT1-1/2, 316L thread
- Electronics; Output: FEM22; 3-wire PNP 10-45VDC
- Housing; Cable entry: F16 Polyester IP66/67 NEMA4X; NPT1/2 Thread
- Additional equipment: Basic version
Technical specifications
- Product type
Vibronic level gauge
- Type
FTM20
- Min. operating voltage
10 V DC
- Max. operating voltage
45 V DC
- Operating voltage
10 - 45 V DC
- Contact type
1 PNP
- Outputs
PNP
- Enclosure material
Polyester
- Model
Capacitive
- Connector
Cable gland
- Min. temperature
-40.0 °C
- Max. temperature
70.0 °C
IP66
IP67
- Content
1 pc(s)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2988632 Endress+Hauser Vibronic level gauge Capacitive FTM20 FTM20-AN23A PNP
Description
The Soliphant FTM20 is a limit switch for applications with fine or coarse-grained, non-fluidized bulk materials. Through the different designs, the device has a broad range of applications. Approvals are also available for use in dust and hazardous areas.
This text is machine translated.
This text is machine translated.
Features
- LINEMeasurement is unaffected by conductivity, adhesion, turbulence, flow or air bubbles
- Easy and quick start-up, no calibration necessary
- No mechanically moving parts, maintenance-free
