Epson Dokumentenscanner Document scanner A4 45 pages/min USB A (USB 3.0)
EAN:
Part number:
Item no:
Highlights & Details
Epson WorkForce DS-790WN - Document scanner - Duplex - A4/Legal - 600 dpi x 600 dpi - up to 45 pages/min. (single-color)
- Advanced authentication features: Set up multiple user accounts locally or remotely (supports LDAP)
- ScanWay - standalone scanning: Scan directly to network, cloud, email, or USB flash drive - no computer required
- Large built-in display: 10.9 cm color touch screen with adjustable presets and layout
Technical specifications
- / Up to 45 pages/min. (Colour) - automatic document feeder (100 sheets) - up to 7000 scans per day - USB 3.0, Gigabit LAN, USB 2.0 (Host),
- Product type
Document scanner
- Scan function
Documents
- Scanning speed
45 pages/min
- Scan area width (min.)
215.9 mm
- Scan area (max.)
6096 mm
- Paper size (max.)
A4
- Document feed
100 Sheet
- Features
Colour touchscreen
- Interfaces
USB A (USB 3.0)
- Duplex unit
Yes
- Traversing light unit
No
- Feeder
Yes
- Flatbed unit
No
- Width
296 mm
- Height
217 mm
- Depth
212 mm
- Dim
(W x H x D) 296 x 217 x 212 mm
- Weight
4.49
- Factory colour
Multicolour
- Input voltage
100 - 240 V
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3732924 Epson Dokumentenscanner Document scanner A4 45 pages/min USB A (USB 3.0)
Description
Prevent unauthorized access to the scanner or use of unauthorized features using a range of authentication methods, including ID cards (card reader not included), credentials, or PIN codes. For advanced security options, use the Epson WebConfig and Document Capture Pro Server - Authentication Edition. Route scanned documents with the 10.9 cm large color touch-screen directly to the right destination, without having to connect yourself with a computer. Scan directly to network and cloud folders, to email addresses or to USB memory stick. The DS-790WN offers a number of connection options, such as USB 3.0, Wi-Fi, Wi-Fi Direct and Gigabit Ethernet. It also supports multiple platforms, including Windows, Mac OS, iOS, Android, Chromebook and Citrix. Scan APP from a smartphone or tablet using the Epson Smart panel. A scanning volume of up to 7,000 pages per day and built-in sensors for detecting paper jams, double feed and dirt on the glass plate help you capture all documents in a high-quality and safe manner.
This text is machine translated.
This text is machine translated.
Features
- Epson WorkForce DS-790WN - Document scanner - Desktop device - USB 3.0, Gigabit LAN, USB 2.0 (host), Wi-Fi(n)
- Device Type : Document Scanner - Desktop Device
- Interface type : USB 3.0, Gigabit LAN, USB 2.0 (host), Wi-Fi(s)
- Additional features : Scan to e-mail, scan to FTP, scan to SharePoint, scan to folder, scan to USB
- Max. Document size supported : 215.9 x 6096 mm
- Input type : color
- Grayscale / Color Depth : 30 bit (1 billion colors)
- Grayscale/Color Depth (External) : 8 bit (256 grayscale) / 24 bit (16.7 million colors)
- Optical resolution : 600 dpi x 600 dpi
- Maximum document scan speed : 45 pages/min. (Single-color) / 45 pages/min. (Colour)
- Automatic Duplex : Yes
- Supported Document Type : Plain Paper
- Document Feeder Type : Automatic
- Document storage capacity : 100 sheets
- Capacity : 7000 scans/day
- Power supply : AC 100-240 V (50/60 Hz)
- System Requirements : Linux, Apple, Mac OS X 10.6.8 or later, Windows 10, Microsoft, Windows 7, Windows 8, Windows 8.1, Microsoft Windows Vista, Microsoft Windows XP SP3, Android, Apple iOS
- Dimensions (width x depth x height): 29.6 cm x 21.2 cm x 21.7 cm
- Weight: 3.7 kg
Scope of delivery
- Driver and Utilities (CD)External power supply with power cable main device Quick start guide USB-3.0-cable
Hints
Scan speed (if stated) refers to A4-sized documents.
