Escha 8063400 Sensor/actuator connector M12 No. of pins (RJ): 3+PE 1 pc(s) Piece
EAN:
Part number:
Item no:
Product type
Sensor/actuator connector
Connection side A
M12 socket, straight
No. of pins
3+PE
Nominal voltage
630 V AC
Nominal current
12.0 A
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Only 2 Piece(s) available
Technical specifications
- Rated voltage 630VAC
- Insulation resistance ≥108 Ω
- Material grip body: Plastic, PA, BK
- Material contacts: Metal, CuZn, gold-plated
- Material contact carrier: Plastic, PA, BK
- Mechanical lifespan >100 mating cycles
- IEC 61076-2-111 standard
- Number of pins 3+PE
- Protection class (mounted) IP67
- Plug connector: Socket, straight, M12
- Current load capacity per pin (at 40°C): 12.0 A
- Ambient temperature: -40°C...+85°C
- Pollution level 3
- Coding: S
- Constant resistance: 3 mΩ
- Connection type: Screw/terminal connection
- Connection cross-section: Max. 1.50 mm²
- Cable outlet 8...10 mm
- Packaging type
Piece
- Type
PS-WAKC4K
- Product type
Sensor/actuator connector
- Connection side A
M12 socket, straight
- No. of pins
3+PE
- Nominal voltage
630 V AC
- Nominal current
12.0 A
- Nominal current - rounded value
12 A
- Connector cross-section (max.)
1.5 mm²
- Cross-section (sensor/actuator wiring)
1.50 mm²
- Connection
Screw terminal
- Thread type connection side
M12
- Coding
S
- Contact material
CuZn
- Contact surface
Gold plated
- max. cross section
1.50 mm²
- Min. temperature
-40 °C
- Max. temperature
85 °C
- Seal type
Screw-on
- Manufacturer part #
8063400
- Content
1 pc(s)
- Cable Ø (max.)
10 mm
- Cable Ø up to
8 mm
- Cable Ø range
8 - 10 mm
Documents & Downloads
Datasheet
Datasheet 3553466 Escha 8063400 Sensor/actuator connector M12 No. of pins (RJ): 3+PE 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3553466 Escha 8063400 Sensor/actuator connector M12 No. of pins (RJ): 3+PE 1 pc(s) Piece
Description
Escha standard connection technology stands for variety, quality and reliability in the protection classes IP67, IP68 and IP69. Thanks to different designs, codes and a variety of cable qualities, you will find the right solution for every application. Whether M8, M12 or M23 round connectors, RJ45 or solenoid connectors – all products come in many cable lengths. Practical T and Y-distributor, panel-mounted plug, adapter and I/O-modules enable a flexible wiring structure.
