ESKA NH 1C 1100V DC 100A NH fuse Suitable for PV fuse Fuse size = 1C 100 A 1100 V DC 1 pc(s)
EAN:
Part number:
Item no:
Product type
NH fuse
Fuse size
1C
Nominal current - rounded value
100 A
Type
Standard
Dim
(W x H x D) 46 x 194 x 61.5 mm
Datasheet (PDF)
Number
Total (€ 96.63 / piece)
€ 96.63
plus VAT.
Highlights & Details
NH fuse type 1C1100 V/DC 100 A
- Suitable for photovoltaic systems
- This text is machine translated.
Technical specifications
- Type
Standard
- Product type
NH fuse
- Fuse size
1C
- Dim
(W x H x D) 46 x 194 x 61.5 mm
- Content
1 pc(s)
- Nominal current
100 A
- Nominal current - rounded value
100 A
- Switch-off capacity
10 kA
- Duty class
gPV
- Size
1C
- Nominal voltage
1100 V DC
- Suitable for
PV fuse
- Width
46 mm
- Height
194 mm
- Depth
61.5 mm
- Blade length
194 mm
Documents & Downloads
Datasheet
Datasheet 520075 ESKA NH 1C 1100V DC 100A NH fuse Suitable for PV fuse Fuse size = 1C 100 A 1100 V DC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 520075 ESKA NH 1C 1100V DC 100A NH fuse Suitable for PV fuse Fuse size = 1C 100 A 1100 V DC 1 pc(s)
Information
Information 520075 ESKA NH 1C 1100V DC 100A NH fuse Suitable for PV fuse Fuse size = 1C 100 A 1100 V DC 1 pc(s)
Description
NH fuses are in the house connection box of single-family homes for the connection to power and all higher performance at low voltage
Used to this. NH fuse, type 1C 100 A, size 1C, 10 kA DC switching capacity, according to IEC 60269-2, 60269-4.
This text is machine translated.
Used to this. NH fuse, type 1C 100 A, size 1C, 10 kA DC switching capacity, according to IEC 60269-2, 60269-4.
