Esotec Rimini Plus 101709 Solar pump set incl. battery
EAN:
Part number:
Item no:
Number
Total (€ 45.37 / piece)
€ 45.37
plus VAT.
Highlights & Details
Solar pumping system Rimini Plus
- Max. delivery head: 0.70 mMax. flow rate 175 l/hWith battery storage5 m power cable4 ascending pipes and 4 nozzle attachments
Technical specifications
- Module: Max. power 3.5 W
- Battery storage: Battery Pack 6 V/1200 mAh
- Current consumption approx. 180 mA
- Hose connection: 8.5 and 10.5 mm
- Dimensions of solar module (L x W x H): 255 x 170 x 22 mm
- Features
incl. battery
- Type
With battery storage 6V/1.2 Ah
- Cable length
5.00 m
- Panel nominal voltage
7.8 V
- Module nominal power
3.5 Wp
- Nominal panel current
450 mA
- Dimensions
(lxbxh) 72 x 36 x 56 mm
- Max. delivery head
0.60 m
- Max. feed rate
175 l/h
- Product type
Solar pump set
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 469374 Esotec Rimini Plus 101709 Solar pump set incl. battery
Description
Ready to plug system with crystalline solar module incl. ground spike and electronic submersible pump with low wear. The battery storage allows cloudy that the pump continues to be in operation. Four different sprays can be generated with the accompanying ascending pipes and nozzles set. The delivery rate of the pump can be adjusted. Ideal for small garden ponds, plant bowls or for supplying smaller waterspouts.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x solar module
- 1x submersible pump
- Cable (5 m)
- Battery storage
- 4x riser pipe, 4x nozzle attachment for differnet water features
- User manual.
