ESYLUX EP10423215 Flush mount Ceiling-mount occupancy sensor White
EAN:
Part number:
Item no:
Technical specifications
- KNX bus system: No.
- Bus system KNX radio: No.
- Bus system wireless bus: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Other bus systems: Without
- Wireless bidirectional: No
- Design: Presence detectors
- Mounting type: Flush-mounted
- Material: Plastic
- Material quality: Thermoplastic
- Surface protection: Untreated
- Design of surface: Matt
- Colour: white
- RAL number (similar): 9010
- Transparent: No.
- With bus connection: Yes
- Low-level detection/back field monitoring: No.
- Operating mode switch: Yes
- Animal slope: No.
- Response brightness adjustable: Yes
- Teach-Function for Response Brightness: Yes
- Switch-off delay, self-learning: No.
- DALI-2 certified: Yes
- Optimum mounting height 2.5 m.
- Max. Range to one side: 4 m.
- Max. Range: Front 3 m
- Capturing field Diameter on floor: 8 m.
- Angle of coverage vertical 58..116°
- Horizontal coverage angle: 180..360°
- Min Depth of the device socket 100 mm
- Product type
Ceiling-mount occupancy sensor
4 m
- Used at
Indoors
- Mounting type
Flush mount
- Factory colour
White
- Similar RAL
9010
- Type
Occupancy Sensors
- Material (details)
Plastic
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3159174 ESYLUX EP10423215 Flush mount Ceiling-mount occupancy sensor White
Description
Design presence detector with excellent detection, at least 8m in diameter. Flat appearance with design covers in plastic: Round, white - variable replacement (alternatively: Square, glass, black). Universal input device for use in conjunction with DALI-2 controllers (e.g. building automation system with DALI-2 interface) or DALI-2 detectors in the room. Integrated PIR sensor for DALI 2 commands in accordance with IEC 62386-303 and light sensor for commands in accordance with IEC 62386-304 button input for connecting conventional 230V buttons. The detector outputs momentary/switching commands as DALI-2 commands in accordance with IEC 62386-301 or -302.
