ESYLUX EP10423222 Flush mount Ceiling-mount occupancy sensor White
EAN:
Part number:
Item no:
Technical specifications
- KNX bus system: No.
- Bus system KNX radio: No.
- Bus system wireless bus: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Design: Presence detectors
- Mounting type: Flush-mounted
- Material: Plastic
- Material quality: Thermoplastic
- Design of surface: Matt
- Colour: white
- RAL number (similar): 9010
- Transparent: No.
- Low-level detection/back field monitoring: Yes
- Animal slope: No.
- Response brightness adjustable: Yes
- Teach-Function for Response Brightness: No.
- DALI-2 certified: No.
- Optimum mounting height 2.5 m.
- Max. Range to one side: 4 m.
- Max. Range: Front 3 m
- Capturing field Diameter on floor: 8 m.
- Angle of coverage vertical 58..116°
- Horizontal coverage angle: 180..360°
- Number of channels: 3
- Min Switch-on time 30 seconds
- Max. duty cycle 720 min
- Min Depth of the device socket 100 mm
- Product type
Ceiling-mount occupancy sensor
8 m
- Mounting type
Flush mount
- Factory colour
White
- Similar RAL
9010
- Type
Occupancy Sensors
- Material (details)
Plastic
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3159184 ESYLUX EP10423222 Flush mount Ceiling-mount occupancy sensor White
Description
KNX design ceiling-mounted occupancy detector with a 360° detection range. Range approx. 8 m Ø at a recommended mounting height of 3 m (maximum mounting height 5 m). Can be used in the KNX bus system (EIB), TP (2-wire bus) in connection with other KNX components. Parameter and function setting via the ETS (engineering tool software). Manual, temporary switching/dimming via user remote control. Communication objects (complete list of communication objects on www.esylux.com), constant light control or switching, heating, ventilation and air conditioning (HVAC), blocked object for heating, ventilation and air conditioning (HVAC), light output (2 bytes), status message, presence output (heating/ventilation climate) HVAC, usable as "
Master"
or "
Slave"
, KNX button control for light channels, full or semi-automatic, orientation light 2 light values selectable 10 % - 50 %, test mode, correction factor for room light, sensitivity sensor adjustable 1 to 4. Standard design as flush-mounted device Ceiling mounting possible with accessories. Targeted suppression of areas using enclosed lens mask.
This text is machine translated.
