ESYLUX EP10427824 Flush mount Ceiling-mount occupancy sensor 360 ° White
EAN:
Part number:
Item no:
Technical specifications
- KNX bus system: No.
- Bus system KNX radio: No.
- Bus system wireless bus: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Design: Presence detectors
- Mounting type: Flush-mounted
- Material: Plastic
- Material quality: Thermoplastic
- Colour: white
- Response brightness adjustable: Yes
- DALI-2 certified: No.
- Optimum mounting height 3 m.
- Max. Range to one side: 4 m.
- Max. Range: Front 3 m
- Capturing field Diameter on floor: 8 m.
- Angle of coverage vertical 53..106°
- Horizontal coverage angle: 180..360°
- Number of channels: 4
- Min Switch-on time 60 seconds
- Max. duty cycle 15 min
- Min Depth of the device socket 24 mm
- Product type
Ceiling-mount occupancy sensor
- Detection angle
360°
8 m
- Mounting type
Flush mount
- Factory colour
White
- Type
Occupancy Sensors
- Material (details)
Plastic
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3159128 ESYLUX EP10427824 Flush mount Ceiling-mount occupancy sensor 360 ° White
Description
Occupancy sensor with 360° detection range for ceiling mounting Range of up to 8 m in diameter at a recommended mounting height of 3 m. Automatic light control of DALI or DALI-2 operating devices at a constant brightness level depending on presence and daylight. Permanently stored factory program for immediate operation. Simple programming via remote control with blue mode technology or by adjustment elements. Integrated switch for setting via remote control or using adjustable controller - to avoid incorrect operation and as tamper protection. Suppression of interference sources by reduction of sensitivity by DIP switches. Additional button input per channel. Detector can be used as a full or semi-automatic system. Reduction of the light output after the end of the follow-up time as orientation light for corridors and passage ranges, adjustable between 10-50% . Integrated switch-off pre-warning. Standard design as flush-mounted device Surface or ceiling mounting with accessories. Cover plate and design ring can be easily changed/painted (silver available as accessory). Extension of the detection range by connection of slave devices. Targeted suppression of areas using enclosed lens mask.
